One-way flow control valve, GGO Series
[Specifications]
・Housing material: Wrought aluminum alloy
・Min. Operating pressure(bar): 0.03
・Max. Operating pressure(bar): 8
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
These valves are used to change a preselected flow rate during a movement sequence. This allows, for example, a preselectable output speed for single- and double-acting cylinders to be changed during operation.
The flow rate or flow rate. Output speed of the piston is set at the pre-control adjustment screw. This anticipates a more or less large part of the actuation path on the roller lever. By actuating the roller lever, the set flow rate or speed is reduced or increased depending on the design. The change can be continuously adjusted within the stroke range by means of the corresponding configuration of the shift cam or a control rail.
The arrows on the nameplate indicate the direction of the adjustable cross-section.
・Housing material: Wrought aluminum alloy
・Min. Operating pressure(bar): 0.03
・Max. Operating pressure(bar): 8
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:-:-]
These valves are used to change a preselected flow rate during a movement sequence. This allows, for example, a preselectable output speed for single- and double-acting cylinders to be changed during operation.
The flow rate or flow rate. Output speed of the piston is set at the pre-control adjustment screw. This anticipates a more or less large part of the actuation path on the roller lever. By actuating the roller lever, the set flow rate or speed is reduced or increased depending on the design. The change can be continuously adjusted within the stroke range by means of the corresponding configuration of the shift cam or a control rail.
The arrows on the nameplate indicate the direction of the adjustable cross-section.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
GGO-1/4-3/8
- Product data
- CAD data not available
Basic information
| Housing material | Wrought aluminum alloy | Seals material | NBR | Adjusting element | Roller lever |
|---|---|---|---|---|---|
| Pneumatic connection 1 | G1/4 | Pneumatic connection 2 | G1/4 | Min. Operating pressure(bar) | 0.03 |
| Max. Operating pressure(bar) | 8 | Min. Ambient temperature(°C) | -10 | Max. Ambient temperature(°C) | 60 |
| Min. Temperature of medium(°C) | -10 | Max. Temperature of medium(°C) | 60 | Standard nominal flow rate in flow control direction(l/min) | 950 |
| Standard nominal flow rate in non-return direction(l/min) | 1150 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Manufacturer part # | 3634 |
| Weight(g) | 400 |
This page is One-way flow control valve, GGO Series, part number GGO-1/4-3/8.
You can find the detail information about specifications and dimensions on part number GGO-1/4-3/8.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
