Shut off valve, MS4 Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| MS4-EE-1/4-10V24 |
| MS4-EE-1/4-10V24-S |
| MS4-EE-1/4-V110 |
| MS4-EE-1/4-V110-S |
| MS4-EE-1/4-V230 |
| MS4-EM1-1/4 |
| MS4-EM1-1/4-S |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Actuation type | Valve function | Seals material | Reset method | Standard nominal flow rate (l/min) | Min. Operating pressure (bar) | Max. Operating pressure (bar) | Min. Temperature of medium (°C) | Max. Temperature of medium (°C) | Max. Ambient temperature (°C) | Pneumatic connection 3 | Degree of protection | C value (l/sbar) | b-value | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
110.17 € | 1 | 3 Days | Electrical | 3/2, closed, monostable | NBR | Mechanical spring | 2000 | 4 | 10 | -10 | 50 | 50 | G1/4 | IP65 | 9.5 | 0.44 | 542578 | 273 | |||
117.78 € | 1 | 3 Days | Electrical | 3/2, closed, monostable | NBR | Mechanical spring | 2000 | 4 | 10 | -10 | 50 | 50 | G1/4 | IP65 | 9.5 | 0.44 | 542598 | 289 | |||
110.17 € | 1 | 4 Days | Electrical | 3/2, closed, monostable | NBR | Mechanical spring | 2000 | 4 | 14 | -10 | 60 | 60 | G1/4 | IP65 | 9.5 | 0.44 | 529535 | 273 | |||
117.78 € | 1 | 22 Days | Electrical | 3/2, closed, monostable | NBR | Mechanical spring | 2000 | 4 | 10 | - | - | 60 | G1/4 | IP65 | 9.5 | 0.44 | 538719 | 289 | |||
110.17 € | 1 | 12 Days | Electrical | 3/2, closed, monostable | NBR | Mechanical spring | 2000 | 4 | 14 | -10 | 60 | 60 | G1/4 | IP65 | 9.5 | 0.44 | 529537 | 273 | |||
42.40 € | 1 | 98 Days | Manual | 3/2, bistable | TPE-U(PU) | - | 2200 | 0 | 14 | -10 | 60 | 60 | G1/4 | - | 9 | 0.39 | 541258 | 190 | |||
50.02 € | 1 | 3 Days | Manual | 3/2, bistable | TPE-U(PU) | - | 2200 | 0 | 14 | -10 | 60 | 60 | Not ducted | - | 9 | 0.39 | 541259 | 210 |
Loading...
Basic information
| Housing material | Die-cast aluminum | Min. Ambient temperature(°C) | -10 | Pneumatic connection 1 | G1/4 |
|---|---|---|---|---|---|
| Pneumatic connection 2 | G1/4 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4], Inert gas | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Configure
Basic Attributes
-
Actuation type
- Electrical
- Manual
-
Valve function
- 3/2, bistable
- 3/2, closed, monostable
-
Seals material
-
Reset method
- Mechanical spring
-
Standard nominal flow rate(l/min)
-
Min. Operating pressure(bar)
- 0
- 4
-
Max. Operating pressure(bar)
- 10
- 14
-
Min. Temperature of medium(°C)
- -10
-
Max. Temperature of medium(°C)
- 50
- 60
-
Max. Ambient temperature(°C)
- 50
- 60
-
Pneumatic connection 3
- G1/4
- Not ducted
-
Degree of protection
- IP65
-
C value(l/sbar)
-
b-value
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 12 Days or Less
- 22 Days or Less
- 98 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
