Pressure regulator, MS6 Series
Click on this image to zoom in.
Click on this image to zoom in.
・Housing material: Die-cast aluminum
・Seals material: NBR
・Operating medium: Compressed air as per ISO 8573-1:2010 [7:4:4], Inert gas
・MS6 Series
[Features]
・Good regulation characteristics with minimal hysteresis and input pressure compensation
・High flow rate performance with minimal pressure drop
・Available with and without secondary exhausting
・Actuator lock to protect the set values from being adjusted
・Four pressure regulation ranges
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Standard nominal flow rate (l/min) | Compressed air filter material | Separating disc material | Pneumatic connection 1 | Pneumatic connection 2 | Min. Pressure regulation (bar) | Max. Pressure regulation | Pressure gauge | Manufacturer part # | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
60.26 € | 1 | 4 Days | 7500 | PE | POM | G1/2 | G1/2 | 0.3 | 4 | with pressure gauge | 529989 | 730 | |||
60.26 € | 1 | 3 Days | 6500 | PE | POM | G1/2 | G1/2 | 0.3 | 7 | with pressure gauge | 529991 | 730 | |||
60.26 € | 1 | 4 Days | 6500 | PE | POM | G1/2 | G1/2 | 0.3 | 7 | with pressure gauge | 529992 | 730 | |||
60.26 € | 1 | 3 Days | 5500 | PE | POM | G1/2 | G1/2 | 0.5 | 12 | with pressure gauge | 529993 | 730 | |||
60.26 € | 1 | 7 Days | 5500 | PE | POM | G1/2 | G1/2 | 0.5 | 12 | with pressure gauge | 529994 | 730 | |||
60.26 € | 1 | 4 Days | 2400 | PE | POM | G1/4 | G1/4 | 0.3 | 4 | with pressure gauge | 529995 | 730 | |||
60.26 € | 1 | 7 Days | 3000 | PE | POM | G1/4 | G1/4 | 0.3 | 7 | with pressure gauge | 529997 | 730 | |||
60.26 € | 1 | 10 Days | 2700 | PE | POM | G1/4 | G1/4 | 0.5 | 12 | with pressure gauge | 529999 | 730 | |||
60.26 € | 1 | 4 Days | 5500 | PE | POM | G3/8 | G3/8 | 0.3 | 4 | with pressure gauge | 530001 | 730 | |||
60.26 € | 1 | 4 Days | 5800 | PE | POM | G3/8 | G3/8 | 0.3 | 7 | with pressure gauge | 530003 | 730 | |||
60.26 € | 1 | 10 Days | 5800 | PE | POM | G3/8 | G3/8 | 0.3 | 7 | with pressure gauge | 530004 | 730 | |||
60.26 € | 1 | 7 Days | 4500 | PE | POM | G3/8 | G3/8 | 0.5 | 12 | with pressure gauge | 530005 | 730 | |||
61.63 € | 1 | 7 Days | 7300 | - | - | G1/2 | G1/2 | 0.3 | 4 | G1/4 prepared | 530320 | 747 | |||
65.43 € | 1 | 7 Days | 7300 | - | - | G1/2 | G1/2 | 0.3 | 4 | with pressure gauge | 530322 | 747 | |||
61.63 € | 1 | 4 Days | 6300 | - | - | G1/2 | G1/2 | 0.3 | 7 | G1/4 prepared | 530326 | 747 | |||
65.43 € | 1 | 7 Days | 6300 | - | - | G1/2 | G1/2 | 0.3 | 7 | with pressure gauge | 530328 | 747 | |||
78.03 € | 1 | 4 Days | 880 | - | - | G1/2 | QS-8 | 0.3 | 7 | with pressure gauge | 530329 | 747 | |||
78.03 € | 1 | 10 Days | 880 | - | - | G1/2 | QS-8 | 0.3 | 7 | with pressure gauge | 530330 | 747 | |||
61.63 € | 1 | 4 Days | 5500 | - | - | G1/2 | G1/2 | 0.5 | 12 | G1/4 prepared | 530332 | 747 | |||
65.43 € | 1 | 7 Days | 5500 | - | - | G1/2 | G1/2 | 0.5 | 12 | with pressure gauge | 530334 | 747 | |||
78.03 € | 1 | 4 Days | 800 | - | - | G1/2 | QS-8 | 0.5 | 12 | with pressure gauge | 530335 | 747 |
Loading...
Basic information
| Operating Pressure Range(MPa) | 0.08::2 | Housing material | Die-cast aluminum | Seals material | NBR |
|---|---|---|---|---|---|
| Material of operator panel | PA, POM | Max. pressure hysteresis(bar) | 0.25 | Min. Ambient temperature(bar) | -10 |
| Max. Ambient temperature(°C) | 60 | Min. Temperature of medium(°C) | -10 | Mix. Temperature of medium(°C) | 60 |
| Min. Storage temperature(°C) | -10 | Max. Storage temperature(°C) | 60 | Size | 6 |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4], Inert gas | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
Configure
Basic Attributes
-
Compressed air filter material
- PE
-
Separating disc material
- POM
-
Pneumatic connection 1
-
Pneumatic connection 2
-
Min. Pressure regulation(bar)
-
Max. Pressure regulation
-
Pressure gauge
- G1/4 prepared
- with pressure gauge
Filter by standard shipping days
-
- All
- 3 Days or Less
- 4 Days or Less
- 7 Days or Less
- 10 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
