FESTO

Three-point gripper, DHDS Series

Three-point gripper, DHDS Series

Part number:

Still undefined. 6 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    DHDS-16-A
    Order suspended
    DHDS-16-A-NC
    DHDS-32-A
    DHDS-32-A-NC
    DHDS-50-A
    DHDS-50-A-NC
    Related

    Operating Pressure Range

    (MPa)

    Size

    Stroke per gripper jaw

    (mm)

    Min. opening time at 6 bar

    (ms)

    Min. closing time at 6 bar

    (ms)

    Mass moment of inertia

    (kgcm²)

    Maximum force on gripper jaw Fz, static

    (N)

    Maximum torque on gripper jaw, Mx static

    (Nm)

    Maximum torque on gripper jaw, My static

    (Nm)

    Maximum torque on gripper jaw, Mz static

    (Nm)

    Max. ground per external gripper finger

    (g)

    Pneumatic connection

    Manufacturer part #

    Weight

    (g)

    		Minimum order quantity

    Data sheet

    0.2～0.8
    16
    2.5
    26 ms
    42 ms
    0.136
    50
    2
    2
    2
    50
    M3
    1259491
    96
    1 pieces

    Data sheet

    0.4～0.8
    16
    2.5
    31 ms
    34 ms
    0.139
    50
    2
    2
    2
    50
    M3
    1259492
    99
    1 pieces

    Data sheet

    0.2～0.8
    32
    3.9
    44 ms
    51 ms
    0.79
    150
    9
    9
    9
    150
    M5
    1259493
    276
    1 pieces

    Data sheet

    0.4～0.8
    32
    3.9
    55 ms
    47 ms
    0.82
    150
    9
    9
    9
    150
    M5
    1259494
    281
    1 pieces

    Data sheet

    0.2～0.8
    50
    6
    62 ms
    55 ms
    6.1
    250
    24
    24
    24
    250
    G1/8
    1259495
    920
    1 pieces

    Data sheet

    0.4～0.8
    50
    6
    73 ms
    50 ms
    6.18
    250
    24
    24
    24
    250
    G1/8
    1259496
    932
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    620.95 €
    ( 738.93 € )
    4 working days
    694.51 €
    ( 826.47 € )
    4 working days
    707.86 €
    ( 842.35 € )
    4 working days
    791.69 €
    ( 942.11 € )
    4 working days
    976.85 €
    ( 1,162.45 € )
    4 working days
    1,092.52 €
    ( 1,300.10 € )
    4 working days
  • 1

    • More Information

    Basic information

    [Specifications]
    ・Housing material: Wrought aluminum alloy, Hard-anodized
    ・Gripper jaw material: High-alloy stainless steel
    ・Cover cap material: PA

    [Features]
    ・Sturdy and precise T-slot guidance of the gripper jaws
    ・High gripping force and compact size
    ・Max. repetition accuracy
    ・Can be used as a double- and single-acting gripper
    ・Single-acting variant or with gripping force backup, normally closed (NC)
    ・Suitable for external and internal gripping
    ・Wide range of adaptation options on the drives
