Sensor box, SRBG Series
・Housing material: PBT
・Material of screws: High-alloy stainless steel
・Degree of protection: IP67
[Features]
・Compact housing with clamped terminal connection for sensor and solenoid valve
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| SRBG-C1-N-1-AS-M12-M12 |
| SRBG-C1-N-1-P-C2-C2 |
| SRBG-C1-N-1-ZU-C2-C2 |
| SRBG-C1-N-1-ZU-M12 |
| SRBG-C1-N-20N-ZC-C2-C2-EX5 |
| SRBG-C1-N-20N-ZC-M12-EX5 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Switching output | Switching element function | Max. switching frequency (Hz) | Max. output current DC (mA) | Voltage drop (V) | Short-circuit protection | Max. Ambient temperature (°C) | Min. Storage temperature (°C) | Max. Storage temperature | DC operating voltage range (V) | Max. switching capacity DC (W) | Manufacturer part number | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
200.09 € | 1 | 4 Days | AS-Interface | N/C contact/N/O contact switchable | 100 | 100 | - | - | 70 | -25 | 70 | 26.5-31.6 | 2.5 | 3567908 | 70 | |||
177.66 € | 1 | 4 Days | PNP | N/O contact | 500 | 100 | ≤ 3 | Pulsed | 70 | -25 | 70 | 10-30 | - | 3568165 | 170 | |||
193.23 € | 1 | 4 Days | Non-contact, 2-wire | N/O contact | 500 | 100 | ≤ 6 | - | 70 | -25 | 70 | 6-60 | - | 3568166 | 170 | |||
166.92 € | 1 | 4 Days | Non-contact, 2-wire | N/O contact | 500 | 100 | ≤ 6 | - | 70 | -25 | 70 | 6-60 | - | 3568056 | 70 | |||
214.97 € | 1 | 21 Days | NAMUR | N/C contact | 3000 | 3 | - | yes | 100 | -40 | 100 | 8.2 | - | 3568167 | 170 | |||
186.43 € | 1 | 21 Days | NAMUR | N/C contact | 3000 | 3 | - | yes | 100 | -40 | 100 | 8.2 | - | 3568057 | 70 |
Loading...
Basic information
| Housing material | PBT | Material of screws | High-alloy stainless steel | Min. Ambient temperature(°C) | -25 |
|---|---|---|---|---|---|
| Degree of protection | IP67 | Contamination level | 3 |
Configure
Basic Attributes
-
Switching output
- Non-contact, 2-wire
- AS-Interface
- NAMUR
- PNP
-
Switching element function
- N/C contact
- N/C contact/N/O contact switchable
- N/O contact
-
Max. switching frequency(Hz)
- 100
- 500
- 3000
-
Max. output current DC(mA)
- 3
- 100
-
Voltage drop(V)
- ≤ 3
- ≤ 6
-
Short-circuit protection
- Pulsed
- yes
-
Max. Ambient temperature(°C)
- 70
- 100
-
Min. Storage temperature(°C)
- -40
- -25
-
Max. Storage temperature
- 70
- 100
-
DC operating voltage range(V)
- 6-60
- 8.2
- 10-30
- 26.5-31.6
-
Max. switching capacity DC(W)
- 2.5
Filter by standard shipping days
-
- All
- 4 Days or Less
- 21 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
