Connecting cable, SIM Series
Click on this image to zoom in.
Click on this image to zoom in.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Housing material | Seals material | Material of cable sheath | Material of pin contacts | Material of union nut | Max. Ambient temperature (°C) | Min. Storage temperature (°C) | Max. Storage temperature (°C) | Degree of protection | DC operating voltage range (V) | Operating voltage range AC (V) | Electrical connection 1, connection type | Electrical connection 1, cable outlet | Electrical connection 1, number of pins/wires | Electrical connection 1, occupied pins/wires | Electrical connection 1, type of mounting | Electrical connection 2, connection type | Electrical connection 2, number of pins/wires | Electrical connection 2, occupied pins/wires | Current rating at 40°C (A) | Surge resistance (kV) | Cable length (m) | Cable diameter tolerance (mm) | Cable design (mm²) | Corrosion resistance class (CRC) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
35.94 € | 1 | 4 Days | TPE-U(PUR) | NBR | TPE-U(PUR) | Brass, gold-plated | - | 70 | -25 | 70 | IP67, IP65 | 0-30 | 0-30 | Socket | Straight | 4 | 4 | Snap-locking | Cable | 4 | 4 | 3 | 0.8 | 2.5 | ± 0.1 | 4 x 0.25 | 4 - Particularly high corrosion stress | 164250 | |||
43.12 € | 1 | 4 Days | TPE-U(PUR) | NBR | TPE-U(PUR) | Brass, gold-plated | - | 70 | -25 | 70 | IP67, IP65 | 0-30 | 0-30 | Socket | Straight | 4 | 4 | Snap-locking | Cable | 4 | 4 | 3 | 0.8 | 5 | ± 0.1 | 4 x 0.25 | 4 - Particularly high corrosion stress | 164251 | |||
35.94 € | 1 | 4 Days | TPE-U(PUR) | NBR | TPE-U(PUR) | Brass, gold-plated | - | 70 | -25 | 70 | IP67, IP65 | 0-30 | 0-30 | Socket | Angled | 4 | 4 | Snap-locking | Cable | 4 | 4 | 3 | 0.8 | 2.5 | ± 0.1 | 4 x 0.25 | 4 - Particularly high corrosion stress | 164252 | |||
43.12 € | 1 | 4 Days | TPE-U(PUR) | NBR | TPE-U(PUR) | Brass, gold-plated | - | 70 | -25 | 70 | IP67, IP65 | 0-30 | 0-30 | Socket | Angled | 4 | 4 | Snap-locking | Cable | 4 | 4 | 3 | 0.8 | 5 | ± 0.1 | 4 x 0.25 | 4 - Particularly high corrosion stress | 164253 | |||
33.78 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-60 | 0-60 | - | - | - | - | - | - | - | - | 4 | 1.5 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159420 | |||
41.48 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-60 | 0-60 | - | - | - | - | - | - | - | - | 4 | 1.5 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159421 | |||
50.52 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159426 | |||
44.78 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159424 | |||
33.78 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-60 | 0-60 | - | - | - | - | - | - | - | - | 4 | 1.5 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159422 | |||
58.11 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159427 | |||
51.65 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159425 | |||
41.48 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-60 | 0-60 | - | - | - | - | - | - | - | - | 4 | 1.5 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159423 | |||
27.43 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-30 | 0-30 | - | - | - | - | - | - | - | - | 4 | 0.8 | 2.5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 158960 | |||
33.06 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-30 | 0-30 | - | - | - | - | - | - | - | - | 4 | 0.8 | 5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 158961 | |||
27.43 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-30 | 0-30 | - | - | - | - | - | - | - | - | 4 | 0.8 | 2.5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 158962 | |||
33.06 € | 1 | 7 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-30 | 0-30 | - | - | - | - | - | - | - | - | 4 | 0.8 | 5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 158963 | |||
39.02 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159428 | |||
46.72 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159429 | |||
49.54 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159432 | |||
39.02 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 2.5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159430 | |||
57.20 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 10-30 | - | - | - | - | - | - | - | - | - | 4 | 0.8 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159433 | |||
46.72 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 5 | - | 3 x 0.25 | 2 - Moderate corrosion stress | 159431 | |||
49.54 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 164259 | |||
49.54 € | 1 | 4 Days | TPE-U(PU) | - | TPE-U(PU) | - | Brass, nickel-plated | 80 | - | - | IP68, IP65 | 0-250 | 0-250 | - | - | - | - | - | - | - | - | 4 | 2.5 | 5 | - | 4 x 0.25 | 2 - Moderate corrosion stress | 164258 |
Loading...
Basic information
| Insulating sheath material | PP | Min. Ambient temperature(°C) | -25 | Contamination level | 3 |
|---|---|---|---|---|---|
| Cable diameter(mm) | 4.5 | Nominal conductor cross section(mm²) | 0.25 | Color cable sheath | Gray |
| Housing colour | Black |
Configure
Basic Attributes
-
Housing material
- TPE-U(PU)
- TPE-U(PUR)
-
Seals material
- NBR
-
Material of cable sheath
- TPE-U(PU)
- TPE-U(PUR)
-
Material of pin contacts
- Brass, gold-plated
-
Material of union nut
- Brass, nickel-plated
-
Max. Ambient temperature(°C)
- 70
- 80
-
Min. Storage temperature(°C)
- -25
-
Max. Storage temperature(°C)
- 70
-
Degree of protection
- IP67, IP65
- IP68, IP65
-
DC operating voltage range(V)
- 0-250
- 0-60
- 0-30
- 10-30
-
Operating voltage range AC(V)
- 0-250
- 0-60
- 0-30
-
Electrical connection 1, connection type
- Socket
-
Electrical connection 1, cable outlet
- Angled
- Straight
-
Electrical connection 1, number of pins/wires
- 4
-
Electrical connection 1, occupied pins/wires
- 4
-
Electrical connection 1, type of mounting
- Snap-locking
-
Electrical connection 2, connection type
- Cable
-
Electrical connection 2, number of pins/wires
- 4
-
Electrical connection 2, occupied pins/wires
- 4
-
Current rating at 40°C(A)
- 3
- 4
-
Surge resistance(kV)
- 0.8
- 1.5
- 2.5
-
Cable length(m)
- 2.5
- 5
-
Cable diameter tolerance(mm)
- ± 0.1
-
Cable design(mm²)
- 3 x 0.25
- 4 x 0.25
-
Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- 4 - Particularly high corrosion stress
Filter by standard shipping days
-
- All
- 4 Days or Less
- 7 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
