Proximity sensor, SMT Series

Basic Attributes

• Design

  • for T-slot
  • for round slot

  Clear

• Housing material

  • Brass, nickel-plated, PA-reinforced, High-alloy stainless steel
  • PA
  • PA-reinforced
  • PA-reinforced, High-alloy stainless steel

  Clear

• Degree of protection

  • IP65, IP68
  • IP65, IP68, IP69K

  Clear

• DC operating voltage range(V)

  • 5-30
  • 7-30
  • 10-30

  Clear

• Type of mounting

  • Clamped in T slot, Can be inserted in slot lengthwise
  • Clamped in round slot, Can be inserted in slot lengthwise
  • Screwed tightly, Can be inserted in slot from above
  • Screwed tightly, Can be inserted in slot lengthwise

  Clear

• Mounting position

  • Any

  Clear

• Cable length(m)

  • 0.3
  • 2.5
  • 5
  • 7.5

  Clear

• Material of cable sheath

  • TPE-U(PU)
  • TPE-U(PUR)

  Clear

• Max. switching frequency(Hz)

  • 150
  • 180

  Clear

• Max. switching capacity DC(W)

  • 2.4
  • 2.8
  • 3

  Clear

• Max. tightening torque(Nm)

  • 0.4
  • 0.6

  Clear

• Switching output

  • Non-contact, 2-wire
  • NPN
  • PNP

  Clear

• Min. Ambient temperature(°C)

  • -40
  • -20

  Clear

• Max. Ambient temperature(°C)

  • 70
  • 85

  Clear

• Repetition accuracy(mm)

  • 0.2

  Clear
