Linear actuator, DGPL Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Stroke: L (mm) | Operating Pressure (MPa) | Size | Max. torque Mz (Nm) | Theoretical force at 6 bar, retracting (N) | Theoretical max. spring return force (N) | Moving mass (g) | Moving mass at 0 mm stroke (g) | Basic weight with 0 mm stroke (g) | Additional moving mass per 10 mm stroke (g) | Cushioning length (mm) | Manufacturer part # | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
2,920.29 € | 1 | 22 Days | 1000 | 0.2～0.8 | 25 | 295 | 295 | G1/8 | 600 | 600 | 1520 | 53 | 18 | 526652 | |||
2,107.92 € | 1 | 22 Days | 250 | 0.2～0.8 | 25 | 295 | 295 | G1/8 | 600 | 600 | 1520 | 53 | 18 | 526649 | |||
2,270.37 € | 1 | 22 Days | 400 | 0.2～0.8 | 25 | 295 | 295 | G1/8 | 600 | 600 | 1520 | 53 | 18 | 526650 | |||
2,378.71 € | 1 | 22 Days | 500 | 0.2～0.8 | 25 | 295 | 295 | G1/8 | 600 | 600 | 1520 | 53 | 18 | 526651 | |||
3,424.38 € | 1 | Quote | 1000 | 0.2～0.8 | 32 | 483 | 483 | G1/8 | 890 | 890 | 2720 | 69 | 20 | 526660 | |||
2,394.05 € | 1 | Quote | 250 | 0.2～0.8 | 32 | 483 | 483 | G1/8 | 890 | 890 | 2720 | 69 | 20 | 526657 | |||
2,600.12 € | 1 | 4 Days | 400 | 0.2～0.8 | 32 | 483 | 483 | G1/8 | 890 | 890 | 2720 | 69 | 20 | 526658 | |||
2,737.52 € | 1 | Quote | 500 | 0.2～0.8 | 32 | 483 | 483 | G1/8 | 890 | 890 | 2720 | 69 | 20 | 526659 | |||
4,187.85 € | 1 | 22 Days | 1000 | 0.15～0.8 | 40 | 754 | 754 | G1/4 | 1700 | 1700 | 4480 | 97 | 30 | 526668 | |||
3,012.66 € | 1 | 22 Days | 250 | 0.15～0.8 | 40 | 754 | 754 | G1/4 | 1700 | 1700 | 4480 | 97 | 30 | 526665 | |||
3,247.69 € | 1 | 24 Days | 400 | 0.15～0.8 | 40 | 754 | 754 | G1/4 | 1700 | 1700 | 4480 | 97 | 30 | 526666 | |||
3,404.38 € | 1 | 22 Days | 500 | 0.15～0.8 | 40 | 754 | 754 | G1/4 | 1700 | 1700 | 4480 | 97 | 30 | 526667 |
Loading...
Basic information
| Cylinder Operation Method | Double Acting | Operating Temperature(℃) | -10::60 | Housing material | Aluminum, Anodized |
|---|---|---|---|---|---|
| Seals material | NBR, TPE-U(PU) | Cover material | Cast aluminum, Coated | Guide | Recirculating ball bearing guide |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 0 - No corrosion stress |
Configure
Basic Attributes
-
Stroke: L(mm)
-
Size
-
Max. torque Mz(Nm)
- 295
- 483
- 754
-
Theoretical force at 6 bar, retracting(N)
-
Theoretical max. spring return force(N)
- G1/4
- G1/8
-
Moving mass(g)
-
Moving mass at 0 mm stroke(g)
-
Basic weight with 0 mm stroke(g)
-
Additional moving mass per 10 mm stroke(g)
-
Cushioning length(mm)
Filter by standard shipping days
-
- All
- 4 Days or Less
- 22 Days or Less
- 24 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
