Stopper cylinder, STAF Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| STAF-80-30-P-A-R |
| STAF-80-40-P-A-R |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Stroke: L (mm) | Permissible impact force on the advanced piston rod | Manufacturer part # | Weight | |
|---|---|---|---|---|---|---|---|---|---|
758.05 € | 1 | Quote | 30 | 14600 N | 164886 | - | |||
770.12 € | 1 | Quote | 40 | 13300 N | 164894 | 5350 |
Loading...
Basic information
| Cylinder Operation Method | Single-Action (Retraction) | Operating Temperature(℃) | 0::60 | Operating Pressure(MPa) | 0.1::1 |
|---|---|---|---|---|---|
| Housing material | Aluminum | Seals material | NBR | Cover material | Aluminum |
| Piston rod material | High-alloy stainless steel | Roller material | Steel | Piston diameter(mm) | 80 |
| Pneumatic connection | G1/8 | Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] | Corrosion resistance class (CRC) | 2 - Moderate corrosion stress |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
