Configure

Voltage
- 24 V DC
Nominal Pipe Thread Size
The above value is for connection securely established between P Port and A Port when positive pressure is applied. For details, see the technical data provided by the relevant manufacturer.
- 1/8
- 1/4
Plumbing
- Direct Plumbing
- Sub-Base Plumbing
CV Value
- 0.74
- 0.77
Lead wire electrical entry
- DIN terminal (with connector)
- DIN terminal (without connector)
Indicator light / Surge voltage suppressor
- With indicator light and surge voltage suppressor (non-polar type)
- Without indicator light / surge voltage suppressor
Bracket
- No bracket
- With Bracket
CE compliant
- CE compliant product
- Non-compliant
Type
- 10-SYJ7□2M□
- 10-SYJ7□4M□
Est. shipping days
- All
- Within 26 working days

3-port solenoid valve Pilot type elastic seal clean series 10-SYJ700 series

Part number:

Still undefined. 3 possible part numbers found.

Part number list

Number of items

Part number

Voltage	Nominal Pipe Thread Size	Plumbing	CV Value	Lead wire electrical entry	Indicator light / Surge voltage suppressor	Bracket	CE compliant	Minimum order quantity

24 V DC	1/8	Direct Plumbing	0.77	DIN terminal (without connector)	Without indicator light / surge voltage suppressor	With Bracket	CE compliant product	1 pieces
24 V DC	1/8	Direct Plumbing	0.77	DIN terminal (with connector)	With indicator light and surge voltage suppressor (non-polar type)	With Bracket	Non-compliant	1 pieces
-	1/4	Sub-Base Plumbing	0.74	DIN terminal (with connector)	With indicator light and surge voltage suppressor (non-polar type)	No bracket	Non-compliant	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

[10-Series Clean Series]
・ Suitable for clean environment
・ It prevents dust generation in the cleanroom

Product images may be representative images only. Please refer to the manufacturer's catalog for shape details.
