Deep groove ball bearings / single row / MC4 / SKF
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
6326 MC4
- Product data
- CAD data not available
Basic information
| Materials of Inner and Outer Ring | Steel | Accuracy (JIS) | Grade 0 | I.D. D(φ) | 130 |
|---|---|---|---|---|---|
| Outer Diameter D(φ) | 280 | Width B(mm) | 58 | Number of Bearing Ring Rows | Single Row |
| Rolling Element Material | Steel | Bore | Cylindrical bore | Cage | Brass cage |
| Clearance | Strongly increased radial clearance | Current insulation | No current insulation | EAN | 7316577099358 |
| Outer ring | Without flange/groove | Seal | None open bearing | Temperature range | -20 to +150 degrees |
| Weight(g) | 17544.0 |
This page is Deep groove ball bearings / single row / MC4 / SKF, part number 6326 MC4.
You can find the detail information about specifications and dimensions on part number 6326 MC4.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
