Deep groove ball bearings / single row / ZC3 / SKF / I.D. D(φ8~110)
・I.D. D(φ): 8~110
・Outer Diameter D(φ): 22~200
・Accuracy (JIS): Grade 0, Grade 5, Grade 6
[Features]
・Shield on one or both sides
・Radial internal clearance greater than Normal
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Accuracy (JIS) | I.D. D (φ) | Outer Diameter D (φ) | Width B (mm) | EAN | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|
154.09 € | 1 | 4 Days | Grade 0 | 55 | 120 | 29 | 7316570846294 | 1510.0 | ||
5.83 € | 1 | 17 Days | Grade 5 | 10 | 26 | 8 | 7316571364650 | 19.0 | ||
6.28 € | 1 | 17 Days | Grade 5 | 12 | 28 | 8 | 7316571364698 | 21.0 | ||
6.88 € | 1 | 17 Days | Grade 5 | 15 | 32 | 9 | 7316571364742 | 29.0 | ||
6.66 € | 1 | 17 Days | Grade 5 | 17 | 35 | 10 | 7316571364773 | 38.0 | ||
9.22 € | 1 | 17 Days | Grade 5 | 25 | 47 | 12 | 7316571364810 | 77.0 | ||
11.57 € | 1 | 17 Days | Grade 6 | 30 | 55 | 13 | 7316571364841 | 115.0 | ||
14.05 € | 1 | 17 Days | Grade 6 | 35 | 62 | 14 | 7316571364889 | 150.0 | ||
15.63 € | 1 | 4 Days | Grade 6 | 40 | 68 | 15 | 7316571364933 | 188.0 | ||
21.25 € | 1 | 4 Days | Grade 6 | 45 | 75 | 16 | 7316577116376 | 239.0 | ||
27.05 € | 1 | 17 Days | Grade 6 | 50 | 80 | 16 | 7316571364988 | 261.0 | ||
34.58 € | 1 | 17 Days | Grade 6 | 55 | 90 | 18 | 7316571366555 | 379.0 | ||
4.77 € | 1 | 17 Days | Grade 5 | 8 | 22 | 7 | 7316570888096 | 12.0 | ||
6.87 € | 1 | 17 Days | Grade 5 | 10 | 30 | 9 | 7316571367057 | 31.0 | ||
7.70 € | 1 | 17 Days | Grade 5 | 15 | 35 | 11 | 7316571367217 | 44.0 | ||
10.13 € | 1 | 17 Days | Grade 5 | 20 | 47 | 14 | 7316571367392 | 104.0 | ||
11.90 € | 1 | 17 Days | Grade 5 | 25 | 52 | 15 | 7316571367460 | 127.00001 | ||
15.45 € | 1 | 17 Days | Grade 6 | 30 | 62 | 16 | 7316571368863 | 196.0 | ||
20.83 € | 1 | 17 Days | Grade 6 | 35 | 72 | 17 | 7316571368986 | 285.0 | ||
39.90 € | 1 | 17 Days | Grade 6 | 50 | 90 | 20 | 7316571369327 | 451.0 | ||
82.35 € | 1 | 17 Days | Grade 0 | 65 | 120 | 23 | 7316571369648 | 1003.99994 | ||
91.63 € | 1 | 17 Days | Grade 0 | 70 | 125 | 24 | 7316571369730 | 1073.0 | ||
94.23 € | 1 | 4 Days | Grade 0 | 75 | 130 | 25 | 7316571369839 | 1172.0 | ||
126.88 € | 1 | 17 Days | Grade 0 | 80 | 140 | 26 | 7316571369945 | 1466.0 | ||
125.50 € | 1 | 4 Days | Grade 0 | 85 | 150 | 28 | 7316571370026 | 1779.0 | ||
204.48 € | 1 | 17 Days | Grade 0 | 90 | 160 | 30 | 7316571370071 | 2204.0 | ||
383.25 € | 1 | 4 Days | Grade 0 | 110 | 200 | 38 | 7316571370170 | 4411.0 | ||
8.65 € | 1 | 17 Days | Grade 5 | 15 | 42 | 13 | 7316571370323 | 80.0 | ||
9.77 € | 1 | 17 Days | Grade 5 | 17 | 47 | 14 | 7316571370392 | 110.0 | ||
11.33 € | 1 | 17 Days | Grade 5 | 20 | 52 | 15 | 7316571370477 | 143.0 | ||
14.23 € | 1 | 17 Days | Grade 6 | 25 | 62 | 17 | 7316571370910 | 221.0 | ||
19.53 € | 1 | 17 Days | Grade 6 | 30 | 72 | 19 | 7316571370903 | 345.0 | ||
26.18 € | 1 | 12 Days | Grade 6 | 35 | 80 | 21 | 7316571370743 | 449.0 | ||
36.32 € | 1 | 17 Days | Grade 6 | 40 | 90 | 23 | 7316570174458 | 618.0 | ||
45.87 € | 1 | 17 Days | Grade 6 | 45 | 100 | 25 | 7316571366135 | 874.0 | ||
76.22 € | 1 | 17 Days | Grade 0 | 55 | 120 | 29 | 7316571366302 | 1353.0 | ||
96.90 € | 1 | 17 Days | Grade 0 | 60 | 130 | 31 | 7316571367637 | 1692.0 | ||
113.14 € | 1 | 4 Days | Grade 0 | 65 | 140 | 33 | 7316571367705 | 2072.0 | ||
142.66 € | 1 | 4 Days | Grade 0 | 70 | 150 | 35 | 7316571367774 | 2518.0 | ||
180.06 € | 1 | 17 Days | Grade 0 | 75 | 160 | 37 | 7316571367811 | 3028.0 | ||
231.20 € | 1 | 17 Days | Grade 0 | 80 | 170 | 39 | 7316571367842 | 3591.0 | ||
271.55 € | 1 | 4 Days | Grade 0 | 95 | 200 | 45 | 7316571367958 | 5689.0 |
Loading...
Basic information
| Materials of Inner and Outer Ring | Steel | Number of Bearing Ring Rows | Single Row | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Bore | Cylindrical bore | Cage | Sheet steel cage | Clearance | Slightly increased radial clearance |
| Current insulation | No current insulation | Outer ring | Without flange/groove | Seal | Cover on one side |
| Temperature range | -20 to +150 degrees |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
