Braided hose【1 to 10 pieces】

Catalog

Part number:

Still undefined. 81 possible part numbers found.

Part number list
Catalog

Part number list

Number of items

Part number

Color

Operating Temperature Range

(℃)

Braided hose features

Bundle diameter (min.)

(mm)

Bundle Ø (max.)

(mm)

Bundle Ø range

Manufacturer part #

Type (manufacturer type)

Minimum order quantity

Green	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243846	CBBOX3037-GN	1 packs 5 pieces
Gray	-40～+150	Dispenser\|Non-abrasive	25	34	25 up to 34 mm	1243878	CBBOX2740-GY	1 packs 5 pieces
Black	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243880	CBBOX0307-BK	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243824	CBBOX3037-BL	1 packs 5 pieces
Black	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243890	CBBOX3037-BK	1 packs 5 pieces
White	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434422	CBBOX0205-WHITE	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243814	CBBOX0307-BL	1 packs 10 pieces
Green	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243836	CBBOX0307-GN	1 packs 10 pieces
Green	-40～+150	Dispenser\|Non-abrasive	25	34	25 up to 34 mm	1243845	CBBOX2534-GN	1 packs 5 pieces
Brown	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243847	CBBOX0307-BN	1 packs 10 pieces
Brown	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243857	CBBOX3037-BN	1 packs 5 pieces
Gray	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1243868	CBBOX0205-GY	1 packs 10 pieces
Gray	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243869	CBBOX0307-GY	1 packs 10 pieces
Gray	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243879	CBBOX3550-GY	1 packs 5 pieces
Black	-40～+150	Dispenser\|Non-abrasive	25	34	25 up to 34 mm	1243889	CBBOX2534-BK	1 packs 5 pieces
White	-40～+150	Dispenser\|Non-abrasive	30	37	30 up to 37 mm	1243901	CBBOX3037-WT	1 packs 5 pieces
Red	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434416	CBBOX0205-RD	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434417	CBBOX0205-BLUE	1 packs 10 pieces
Green	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434419	CBBOX0205-GREEN	1 packs 10 pieces
Brown	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434420	CBBOX0205-BROWN	1 packs 10 pieces
Black	-40～+150	Dispenser\|Non-abrasive	2	5	2 up to 5 mm	1434421	CBBOX0205-Black	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243803	CBBOX0307-RD	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	3	7	3 up to 7 mm	1243825	CBBOX0307-YL	1 packs 10 pieces
White	-40～+150	Dispenser\|Non-abrasive	25	34	25 up to 34 mm	1243900	CBBOX2534-WT	1 packs 5 pieces
Black	-40～+125	non-flammable\|coarse braid	12.7	12.7	12.70 up to 12.70 mm	542882	BS1000-FR3	1 pieces
Black	-40～+125	non-flammable\|coarse braid	3.20	3.20	3.20 up to 3.20 mm	542852	BS1000-FR1	1 pieces
Black	-40～+125	non-flammable\|coarse braid	6.40	6.40	6.40 up to 6.40 mm	542867	BS1000-FR2	1 pieces
White	-40～+125	non-flammable\|coarse braid	3.20	3.20	3.20 up to 3.20 mm	546801	BS1000-FR1-W	1 pieces
Red	-40～+150	Dispenser\|Non-abrasive	6	12	6 up to 12 mm	1243806	CBBOX0612-RD	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	4	8	4 up to 8 mm	1243815	CBBOX0408-BL	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	8	14	8 up to 14 mm	1243818	CBBOX0814-BL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	5	10	5 up to 10 mm	1243827	CBBOX0510-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	12	21	12 up to 21 mm	1243831	CBBOX1221-YL	1 packs 10 pieces
Green	-40～+150	Dispenser\|Non-abrasive	8	14	8 up to 14 mm	1243840	CBBOX0814-GN	1 packs 10 pieces
Brown	-40～+150	Dispenser\|Non-abrasive	12	21	12 up to 21 mm	1243853	CBBOX1221-BN	1 packs 10 pieces
Brown	-40～+150	Dispenser\|Non-abrasive	15	27	15 up to 27 mm	1243854	CBBOX1527-BN	1 packs 10 pieces
Orange	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243859	CBBOX1015-OR	1 packs 10 pieces
Gray	-40～+150	Dispenser\|Non-abrasive	4	8	4 up to 8 mm	1243870	CBBOX0409-GY	1 packs 10 pieces
Black	-40～+150	Dispenser\|Non-abrasive	4	8	4 up to 8 mm	1243881	CBBOX0408-BK	1 packs 10 pieces
Black	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243885	CBBOX1015-BK	1 packs 10 pieces
White	-40～+150	Dispenser\|Non-abrasive	8	14	8 up to 14 mm	1243895	CBBOX0814-WT	1 packs 10 pieces
White	-40～+150	Dispenser\|Non-abrasive	12	21	12 up to 21 mm	1243897	CBBOX1221-WT	1 packs 10 pieces
Orange	-40～+150	Dispenser\|Non-abrasive	15	27	15 up to 27 mm	1243902	CBBOX1527-OR	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	4	8	4 up to 8 mm	1243804	CBBOX0408-RD	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	5	10	5 up to 10 mm	1243805	CBBOX0510-RD	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	8	14	8 up to 14 mm	1243807	CBBOX0814-RD	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243808	CBBOX1015-RD	1 packs 10 pieces
Red	-40～+150	Dispenser\|Non-abrasive	15	27	15 up to 27 mm	1243810	CBBOX1527-RD	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	6	12	6 up to 12 mm	1243817	CBBOX0612-BL	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243819	CBBOX1015-BL	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	12	21	12 up to 21 mm	1243820	CBBOX1221-BL	1 packs 10 pieces
Blue	-40～+150	Dispenser\|Non-abrasive	20	28	20 up to 28 mm	1243822	CBBOX2028-BL	1 packs 5 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	4	8	4 up to 8 mm	1243826	CBBOX0408-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	6	12	6 up to 12 mm	1243828	CBBOX0612-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	8	14	8 up to 14 mm	1243829	CBBOX0814-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243830	CBBOX1015-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	15	27	15 up to 27 mm	1243832	CBBOX1527-YL	1 packs 10 pieces
Yellow	-40～+150	Dispenser\|Non-abrasive	20	28	20 up to 28 mm	1243833	CBBOX2028-YL	1 packs 5 pieces
Green	-40～+150	Dispenser\|Non-abrasive	6	12	6 up to 12 mm	1243839	CBBOX0612-GN	1 packs 10 pieces
Green	-40～+150	Dispenser\|Non-abrasive	10	15	10 up to 15 mm	1243841	CBBOX1015-GN	1 packs 10 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

20.23 € ( 24.07 € )	3 working days
16.93 € ( 20.15 € )	3 working days
14.81 € ( 17.62 € )	3 working days
23.41 € ( 27.86 € )	3 working days
19.16 € ( 22.80 € )	3 working days
14.81 € ( 17.62 € )	3 working days
13.75 € ( 16.36 € )	3 working days
14.81 € ( 17.62 € )	3 working days
17.99 € ( 21.41 € )	3 working days
14.81 € ( 17.62 € )	3 working days
17.99 € ( 21.41 € )	3 working days
14.81 € ( 17.62 € )	3 working days
14.81 € ( 17.62 € )	3 working days
24.48 € ( 29.13 € )	3 working days
20.23 € ( 24.07 € )	3 working days
22.35 € ( 26.60 € )	3 working days
14.81 € ( 17.62 € )	98 working days
12.67 € ( 15.08 € )	3 working days
14.81 € ( 17.62 € )	3 working days
12.67 € ( 15.08 € )	3 working days
13.75 € ( 16.36 € )	3 working days
14.81 € ( 17.62 € )	3 working days
14.81 € ( 17.62 € )	3 working days
20.23 € ( 24.07 € )	3 working days
4.13 € ( 4.91 € )	3 working days
2.89 € ( 3.44 € )	3 working days
3.61 € ( 4.30 € )	3 working days
0.96 € ( 1.14 € )	3 working days
15.87 € ( 18.89 € )	35 working days
14.81 € ( 17.62 € )	3 working days
15.87 € ( 18.89 € )	3 working days
15.87 € ( 18.89 € )	3 working days
17.99 € ( 21.41 € )	3 working days
16.93 € ( 20.15 € )	3 working days
16.93 € ( 20.15 € )	3 working days
8.95 € ( 10.65 € )	3 working days
17.99 € ( 21.41 € )	3 working days
14.81 € ( 17.62 € )	3 working days
15.87 € ( 18.89 € )	3 working days
16.93 € ( 20.15 € )	3 working days
15.87 € ( 18.89 € )	3 working days
15.87 € ( 18.89 € )	3 working days
20.23 € ( 24.07 € )	3 working days
14.81 € ( 17.62 € )	3 working days
15.87 € ( 18.89 € )	3 working days
15.87 € ( 18.89 € )	3 working days
17.99 € ( 21.41 € )	3 working days
19.16 € ( 22.80 € )	3 working days
14.81 € ( 17.62 € )	3 working days
16.93 € ( 20.15 € )	3 working days
19.16 € ( 22.80 € )	3 working days
19.16 € ( 22.80 € )	3 working days
15.87 € ( 18.89 € )	3 working days
15.87 € ( 18.89 € )	3 working days
16.93 € ( 20.15 € )	3 working days
17.99 € ( 21.41 € )	3 working days
19.16 € ( 22.80 € )	3 working days
19.16 € ( 22.80 € )	3 working days
15.87 € ( 18.89 € )	3 working days
16.93 € ( 20.15 € )	3 working days
