Retroreflective photo sensor
- Volume Discount
・Product type: Retroreflective photo sensor
・Sensor features: LED indicator
・IP rating: IP67, IP69K
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Cable length (m) | Connector (sensor) | Contact type | Enclosure material | Functions (light barriers) | IP rating | Laser class | Light emission | Max. operating voltage (V DC) | Max. range (open field) (cm) | Max. range (open field) (mm) | Max. temperature (°C) | Min. operating voltage (V DC) | Min. temperature (°C) | Operating voltage (range) | Outputs (sensors) | Product size (height) (mm) | Product size (width) (mm) | Product size (length) (mm) | Response time (ms) | Response time (µs) | Switching frequency (Hz) | Switching frequency (kHz) | Transmitter type | Type (manufacturer type) | Wavelength (nm) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
65.03 € | 1 | Available | 12 Days | - | M8 (4-pin) | - | - | Light-ON | IP67 | - | - | 30 | - | 700 | +55 | 10 | -25 | 10 - 30 V DC | PNP | 11 | 19 | 31 | 1 | - | 500 | - | LED IR | S3Z-PR-5-C11-PL | 870 | |
71.55 € | 1 | Available | 18 Days | - | M8 (4-pin) | - | - | Light-ON | IP67 | - | - | 30 | - | 150 | +55 | 10 | -25 | 10 - 30 V DC | PNP | 11 | 19 | 31 | 1 | - | 500 | - | LED red | S3Z-PR-5-C01-PL | 665 | |
104.57 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | Light-ON | IP67 | - | - | 30 | - | 300 | +55 | 10 | -25 | 10 - 30 V DC | PNP | 11 | 19 | 31 | 1 | - | 500 | - | LED red | S3Z-PR-5-M01-PL | 665 | |
185.83 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | Light-ON|Dark-ON|Background suppression | IP67 | 1 | - | 30 | - | 300 | +55 | 10 | -25 | 10 - 30 V DC | PNP | 11 | 19 | 31 | - | 250 | - | 2 | SC laser red | S3Z-PH-5-M01-PP | 650 | |
256.88 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | Acrylonitrile butadiene styrene | Light-ON|Dark-ON|Background suppression | IP67 | 2 | - | 30 | - | 200 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 25 | 14 | 42 | - | 100 | - | 5 | SC laser red | S8-PH-5-M01-PP | 665 | |
89.32 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | Acrylonitrile butadiene styrene | Light-ON|Dark-ON | IP67 | - | - | 30 | 50 | - | +55 | 10 | -10 | 10 - 30 V DC | PNP | 25 | 14 | 42 | - | 500 | - | 1 | LED red | S8-PR-5-C01-PP | 660 | |
224.08 € | 1 | Available | 13 Days | - | M8 (4-pin) | - | Stainless steel | Light-ON|Dark-ON|Background suppression | IP69K | - | - | 30 | - | 300 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 25 | 14 | 42 | 1 | - | 500 | - | LED red | S8-MR-5-M01-PP | 660 | |
48.77 € | 1 | Available | 3 Days | 2 | Cable. open end | - | - | - | IP67 | - | - | 30 | - | 300 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-2-C00-PK | 632 | |
54.20 € | 1 | Available | 34 Days | 2 | Cable. open end | - | - | - | IP67 | - | - | 30 | - | 300 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-2-C10-PK | 632 | |
60.69 € | 1 | Available | 3 Days | 2 | Cable. open end | - | - | Fixed focus | IP67 | - | - | 30 | - | 70 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-2-D00-PK | 632 | |
65.03 € | 1 | Available | 3 Days | 2 | Cable. open end | - | - | Light-ON|Dark-ON|Background suppression|Teach-in | IP67 | - | - | 30 | - | 100 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-2-M00-PH | 632 | |
49.85 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | - | IP67 | - | - | 30 | - | 300 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-5-C00-PK | 632 | |
52.03 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | - | IP67 | - | - | 30 | - | 500 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-5-C10-PK | 632 | |
60.69 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | Fixed focus | IP67 | - | - | 30 | - | 70 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-5-D00-PK | 632 | |
78.43 € | 1 | Available | 3 Days | - | M8 (4-pin) | - | - | Light-ON|Dark-ON|Background suppression|Teach-in | IP67 | - | - | 30 | - | 100 | +55 | 10 | -20 | 10 - 30 V DC | PNP | 12 | 20 | 32 | 1 | - | 500 | - | LED red | S100-PR-5-M00-PH | 632 | |
65.03 € | 1 | Available | 3 Days | - | M12 (4-pin) | 1 maker|1 breaker | Plastic | Light-ON|Dark-ON | IP67 | - | axial | 30 | - | 100 | +55 | 10 | -25 | 10 - 30 V DC | PNP | - | - | - | 0.5 | - | - | 1 | LED IR | S50-PA-5-C10-PP | 880 | |
145.65 € | 1 | 3 Days | - | M12 (4-pin) | 1 maker|1 breaker | Plastic | Light-ON|Dark-ON|Trimmer | IP67 | 1 | axial | 30 | - | 350 | +50 | 10 | -10 | 10 - 30 V DC | PNP | - | - | - | - | 333 | - | 1 | SC laser red | S50-PL-5-C01-PP | 650 | ||
82.77 € | 1 | Available | 3 Days | - | M12 (4-pin) | 1 maker|1 breaker | Metal | Light-ON|Dark-ON|Trimmer | IP67 | - | axial | 30 | - | 400 | +55 | 10 | -25 | 10 - 30 V DC | PNP | - | - | - | 0.5 | - | - | 1 | LED IR | S50-MA-5-C21-PP | 880 | |
153.03 € | 1 | Available | 3 Days | - | M12 (4-pin) | - | - | Background suppression|Trimmer | IP67 | - | - | 30 | - | 300 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 140 | - | 1 | LED IR | S62-PA-5-M01-PP | 880 | |
191.29 € | 1 | Available | 3 Days | - | M12 (4-pin) | - | - | Background suppression|Trimmer | IP67 | - | - | 30 | - | 600 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 500 | - | 1 | LED IR | S62-PA-5-M11-PP | 880 | |
262.35 € | 1 | Available | 3 Days | - | M12 (4-pin) | - | - | Background suppression|Trimmer | IP67 | 2 | - | 30 | - | 150 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 140 | - | 3.5 | SC laser red | S62-PL-5-M01-PP | 665 | |
322.48 € | 1 | Available | 3 Days | - | M12 (4-pin) | - | - | Background suppression|Trimmer | IP67 | 2 | - | 30 | - | 600 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 200 | - | 2.5 | SC laser red | S62-PL-5-M11-PP | 665 | |
153.03 € | 1 | Available | 3 Days | - | Cable. open end | - | - | Trimmer | IP67 | - | - | 60|240 | - | 2000 | +55 | 24|24 | -10 | 24. 24 - 60. 240 V DC. V AC | Relay contact | 18 | 50 | 50 | 1 | - | 20 | - | LED red | S62-PA-1-C11-RX | 640 | |
84.96 € | 1 | Available | 11 Days | - | M12 (4-pin) | - | - | Trimmer | IP67 | - | - | 30 | - | 900 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 500 | - | 1 | LED red | S62-PA-5-C01-PP | 640 | |
114.37 € | 1 | Available | 3 Days | - | M12 (4-pin) | - | - | Trimmer | IP67 | - | - | 30 | - | 2000 | +55 | 10 | -10 | 10 - 30 V DC | PNP | 18 | 50 | 50 | - | 500 | - | 1 | LED red | S62-PA-5-C11-PP | 640 |
Loading...
Basic information
| Product type | Retroreflective photo sensor | Sensor features | LED indicator |
|---|
Configure
Basic Attributes
-
Cable length(m)
-
Connector (sensor)
-
Contact type
-
Enclosure material
-
Functions (light barriers)
-
IP rating
-
Laser class
-
Light emission
-
Max. operating voltage(V DC)
-
Max. range (open field)(cm)
-
Max. range (open field)(mm)
-
Max. temperature(°C)
-
Min. operating voltage(V DC)
-
Min. temperature(°C)
-
Operating voltage (range)
-
Outputs (sensors)
-
Product size (height)(mm)
-
Product size (width)(mm)
-
Product size (length)(mm)
-
Response time(ms)
-
Response time(µs)
-
Switching frequency(Hz)
-
Switching frequency(kHz)
-
Transmitter type
-
Type (manufacturer type)
-
Wavelength(nm)
Filter by standard shipping days
-
- All
- 3 Days or Less
- 11 Days or Less
- 12 Days or Less
- 13 Days or Less
- 18 Days or Less
- 34 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
