Deep groove ball bearings / single row / 6210 / HT200 / HT200 / SNR
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
6210 HT200
- Product data
- CAD data not available
Basic information
| Materials of Inner and Outer Ring | Steel | Accuracy (JIS) | Grade 0 | I.D. D(φ) | 50 |
|---|---|---|---|---|---|
| Outer Diameter D(φ) | 90 | Width B(mm) | 20 | Number of Bearing Ring Rows | Single Row |
| Rolling Element Material | Steel | Bore | Cylindrical bore | Cage | Sheet steel cage |
| Clearance | Strongly increased radial clearance | Current insulation | No current insulation | EAN | 3413520353278 |
| Outer ring | Without flange/groove | Seal | Non-contact seal on both sides | Temperature range | Special grease (-20 to +200 °C) |
| Weight(g) | 482.0 |
This page is Deep groove ball bearings / single row / 6210 / HT200 / HT200 / SNR, part number 6210 HT200.
You can find the detail information about specifications and dimensions on part number 6210 HT200.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
