Roller Bearings MB Series
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 81228 MB |
| 81230 MB |
| 89317 MB |
| 89320 MB |
| K81228 MB |
| K81230 MB |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. d (mm) | O.D. D (mm) | Width B (mm) | Cage | EAN | Product range | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
460.17 € | 1 | 4 Days | 140 | 200 | 46 | Brass cage | 9008745738142 | Complete axial cylindrical roller bearing | 5000.0 | ||
597.89 € | 1 | 4 Days | 150 | 215 | 50 | Brass cage | 9008745738159 | Complete axial cylindrical roller bearing | 7000.0 | ||
395.16 € | 1 | 4 Days | 85 | 150 | 39 | Brass cage | 9008745727955 | Complete axial cylindrical roller bearing | 3390.0 | ||
457.12 € | 1 | 4 Days | 100 | 170 | 42 | Brass cage | 9008745727979 | Complete axial cylindrical roller bearing | 4560.0 | ||
229.50 € | 1 | 4 Days | 140 | 197 | 19 | Polyamide cage | 9008745231940 | Axial cylindrical roller and cage assembly only | 1800.0 | ||
259.53 € | 1 | 4 Days | 150 | 212 | 21 | Polyamide cage | 9008745231957 | Axial cylindrical roller and cage assembly only | 2810.0 |
Loading...
Basic information
| Inner/Outer Ring Material | Steel | Precision (JIS) | Class 0 | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Angular adjustment | Non-angle adjustable | Operating direction | Single direction bearing | Temperature range | -20 to +120 °C |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
