Angular contact ball bearings / single row / 7310 / plastic cage / BEGBP / BEGBP / SKF
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
7310 BEGBP
- Product data
- CAD data not available
Basic information
| Materials of Inner and Outer Ring | Steel | Accuracy (JIS) | Grade 5 | I.D. D(φ) | 50 |
|---|---|---|---|---|---|
| Outer Diameter D(φ) | 110 | Width B(mm) | 27 | Number of Bearing Ring Rows | Single Row |
| Rolling Element Material | Steel | Arrangement | Standard version | Cage | Polyamide cage |
| Clearance | Normal radial clearance | Contact angle | 40 degrees | EAN | 7316577150653 |
| Seal | None. open bearing | Temperature range | -20 to +120 °C | Weight(g) | 1038.0 |
This page is Angular contact ball bearings / single row / 7310 / plastic cage / BEGBP / BEGBP / SKF, part number 7310 BEGBP.
You can find the detail information about specifications and dimensions on part number 7310 BEGBP.
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
