Deep groove ball bearings / single row / M / NKE BEARINGS
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 16048 M |
| 6017 M |
| 6236 M |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Accuracy (JIS) | I.D. D (φ) | Outer Diameter D (φ) | Width B (mm) | EAN | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|
979.68 € | 1 | 4 Days | Grade 0 | 240 | 360 | 37 | 9008745104411 | 14300.0 | ||
105.53 € | 1 | 4 Days | Grade 0 | 85 | 130 | 22 | 9008745154539 | 890 | ||
798.80 € | 1 | 4 Days | - | 180 | 320 | 52 | - | 18200.0 |
Loading...
Basic information
| Materials of Inner and Outer Ring | Steel | Number of Bearing Ring Rows | Single Row | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Bore | Cylindrical bore | Cage | Brass cage | Clearance | Normal radial clearance |
| Current insulation | No current insulation | Outer ring | Without flange/groove | Seal | None. open bearing |
| Temperature range | -20 to +150 °C |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
