Axial deep groove ball bearings
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 51104 |
| 51111 |
| 51117 |
| 51118 |
| 51136 |
| 51212 |
| 51217 |
| 51230 |
| 51232 |
| 51312 |
| 51318 |
| 51322 |
| 51324 |
| 51330 |
| 52202 |
| BA6 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. D (φ) | Outer Diameter D (φ) | Width B (mm) | Weight (g) | Operating direction | |
|---|---|---|---|---|---|---|---|---|---|
1.72 € | 1 | 4 Days | 20 | 35 | 10 | 40.0 | Single direction bearing | ||
5.10 € | 1 | 4 Days | 55 | 78 | 16 | 213.0 | Single direction bearing | ||
18.55 € | 1 | 4 Days | 85 | 110 | 19 | 432.0 | Single direction bearing | ||
18.22 € | 1 | 4 Days | 90 | 120 | 22 | 692.0 | Single direction bearing | ||
325.92 € | 1 | 4 Days | 180 | 225 | 34 | 2891.0 | Single direction bearing | ||
13.90 € | 1 | 4 Days | 60 | 95 | 26 | 687.0 | Single direction bearing | ||
25.53 € | 1 | 4 Days | 85 | 125 | 31 | 1223.0 | Single direction bearing | ||
142.19 € | 1 | 4 Days | 150 | 215 | 50 | 5620.0 | Single direction bearing | ||
479.98 € | 1 | 4 Days | 160 | 225 | 51 | 5820.0 | Single direction bearing | ||
28.58 € | 1 | 4 Days | 60 | 110 | 35 | 1410.0 | Single direction bearing | ||
89.04 € | 1 | 4 Days | 90 | 155 | 50 | 3082.0 | Single direction bearing | ||
137.93 € | 1 | 4 Days | 110 | 190 | 63 | 7441.0 | Single direction bearing | ||
- | 1 | Quote | 120 | 210 | 70 | 9636.0 | Single direction bearing | ||
290.70 € | 1 | 4 Days | 150 | 250 | 80 | 14940.0 | Single direction bearing | ||
4.45 € | 1 | 4 Days | 10 | 32 | 22 | 80.0 | Double direction bearing | ||
4.35 € | 1 | 4 Days | 6 | 14 | 5 | 5.0 | Single direction bearing |
Loading...
Basic information
| Materials of Inner and Outer Ring | Steel | Accuracy (JIS) | Grade 0 | Rolling Element Material | Steel |
|---|---|---|---|---|---|
| Cage | Sheet steel cage | Temperature range | -30 to +150 °C | Angular adjustment | Non-angle adjustable |
| Product range | Axial deep groove ball bearing. without washer(s) |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
