Air Slide Table, Height Interchangeable Type, MXQ Series
· Tailor MXQ to your individual needs: 4 body types, 4 stroke adjuster types, centralised adjuster, buffer mechanism, end lock, axial piping and several extra options including dual stroke and special environment specifications
· Avoid undesired moments, oscillations and vibrations: Double rod construction & low centre of gravity design
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Stroke (mm) | Cylinder Inner Diameter (Ø) | Type | |
|---|---|---|---|---|---|---|---|
358.32 € | 1 | 4 Days | 10 | 6 | Standard | ||
397.82 € | 1 | 4 Days | 20 | 6 | Standard | ||
437.42 € | 1 | 4 Days | 30 | 6 | Standard | ||
481.66 € | 1 | 4 Days | 40 | 6 | Standard | ||
523.52 € | 1 | 4 Days | 50 | 6 | Standard | ||
358.32 € | 1 | 4 Days | 10 | 6 | Symmetric type | ||
397.82 € | 1 | 4 Days | 20 | 6 | Symmetric type | ||
437.42 € | 1 | 4 Days | 30 | 6 | Symmetric type | ||
481.66 € | 1 | 4 Days | 40 | 6 | Symmetric type | ||
523.52 € | 1 | 26 Days | 50 | 6 | Symmetric type | ||
409.53 € | 1 | 4 Days | 10 | 8 | Standard | ||
409.53 € | 1 | 4 Days | 20 | 8 | Standard | ||
451.37 € | 1 | 4 Days | 30 | 8 | Standard | ||
493.27 € | 1 | 4 Days | 40 | 8 | Standard | ||
535.11 € | 1 | 4 Days | 50 | 8 | Standard | ||
639.87 € | 1 | 7 Days | 75 | 8 | Standard | ||
409.53 € | 1 | 4 Days | 10 | 8 | Symmetric type | ||
409.53 € | 1 | 4 Days | 20 | 8 | Symmetric type | ||
451.37 € | 1 | 4 Days | 30 | 8 | Symmetric type | ||
493.27 € | 1 | 4 Days | 40 | 8 | Symmetric type | ||
535.11 € | 1 | 7 Days | 50 | 8 | Symmetric type | ||
639.87 € | 1 | 4 Days | 75 | 8 | Symmetric type | ||
465.31 € | 1 | 4 Days | 10 | 12 | Standard | ||
465.31 € | 1 | 4 Days | 20 | 12 | Standard | ||
465.31 € | 1 | 4 Days | 30 | 12 | Standard | ||
507.23 € | 1 | 4 Days | 40 | 12 | Standard | ||
549.13 € | 1 | 4 Days | 50 | 12 | Standard | ||
653.82 € | 1 | 4 Days | 75 | 12 | Standard | ||
758.48 € | 1 | 4 Days | 100 | 12 | Standard | ||
465.31 € | 1 | 4 Days | 10 | 12 | Symmetric type | ||
465.31 € | 1 | 4 Days | 20 | 12 | Symmetric type | ||
465.31 € | 1 | 4 Days | 30 | 12 | Symmetric type | ||
507.23 € | 1 | 4 Days | 40 | 12 | Symmetric type | ||
549.13 € | 1 | 4 Days | 50 | 12 | Symmetric type | ||
653.82 € | 1 | 7 Days | 75 | 12 | Symmetric type | ||
758.48 € | 1 | 4 Days | 100 | 12 | Symmetric type | ||
479.34 € | 1 | 4 Days | 10 | 16 | Standard | ||
479.34 € | 1 | 4 Days | 20 | 16 | Standard | ||
479.34 € | 1 | 4 Days | 30 | 16 | Standard | ||
521.18 € | 1 | 4 Days | 40 | 16 | Standard | ||
563.08 € | 1 | 4 Days | 50 | 16 | Standard | ||
667.76 € | 1 | 4 Days | 75 | 16 | Standard | ||
772.50 € | 1 | 4 Days | 100 | 16 | Standard | ||
877.18 € | 1 | 4 Days | 125 | 16 | Standard | ||
518.85 € | 1 | 4 Days | 10 | 20 | Standard | ||
518.85 € | 1 | 4 Days | 20 | 20 | Standard | ||
518.85 € | 1 | 4 Days | 30 | 20 | Standard | ||
560.76 € | 1 | 4 Days | 40 | 20 | Standard | ||
602.60 € | 1 | 4 Days | 50 | 20 | Standard | ||
707.35 € | 1 | 4 Days | 75 | 20 | Standard | ||
812.02 € | 1 | 4 Days | 100 | 20 | Standard | ||
916.77 € | 1 | 4 Days | 125 | 20 | Standard | ||
1,021.44 € | 1 | 4 Days | 150 | 20 | Standard | ||
600.27 € | 1 | 26 Days | 10 | 25 | Standard | ||
600.27 € | 1 | 4 Days | 20 | 25 | Standard | ||
600.27 € | 1 | 4 Days | 30 | 25 | Standard | ||
646.84 € | 1 | 4 Days | 40 | 25 | Standard | ||
693.32 € | 1 | 4 Days | 50 | 25 | Standard | ||
809.69 € | 1 | 4 Days | 75 | 25 | Standard | ||
926.06 € | 1 | 4 Days | 100 | 25 | Standard |
Loading...
Basic information
| Adjuster Option | Without adjuster | Auto Switch | None | Custom-made Specifications | None |
|---|
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
