SKF Felt Strips
・Shaft tolerance class: h9
Felt strips, and their high-temperature variants made of aluminium borosilicate, provide a simple and effective sealing solution.
[Features]
・They accommodate relatively high shaft speeds, because a small gap forms between the felt strip and the shaft, transforming the seal into a non-contact, gap-type seal
・Felt strips should be cut to the correct length and soaked in hot oil prior to being installed
・Cost-effective
・Suitable for relatively high shaft speeds
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| FS 110 |
| FS 170 |
| FS 180 |
| FS 190 |
| FS 260 |
| FS 300 |
| FS 330 |
| FS 370 |
| FS 460 |
| FS 510 |
| FS 680 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Customs tariff weight (kg) | |
|---|---|---|---|---|---|
0.35 € | 1 | 5 Days | 0 | ||
0.63 € | 1 | 5 Days | 0.002 | ||
0.63 € | 1 | 5 Days | 0 | ||
0.86 € | 1 | 5 Days | 0.002 | ||
2.37 € | 1 | 5 Days | 0.029 | ||
1.34 € | 1 | 5 Days | 0.002 | ||
3.62 € | 1 | 5 Days | 0.007 | ||
5.95 € | 1 | 5 Days | 0.009 | ||
10.05 € | 1 | 5 Days | 0.012 | ||
12.97 € | 1 | 5 Days | 0.021 | ||
25.94 € | 1 | 5 Days | 0.028 |
Loading...
Basic information
| Temperature range | -40 to 100 °C | Version(g) | Felt strips | Use with splash water | less suitable |
|---|---|---|---|---|---|
| Use with low friction | hardly suitable | Use with vertical shaft | not suitable | Customs tariff weight unit | kg |
| Use in direct sunlight | very suitable | Shaft tolerance class | h9 | Roughness of the shaft Ra(µm) | <=3.2 |
| Use with axial displacement | very suitable | Use with coarse particles | suitable | max. inclination(°) | 0.5 |
| Use with chips, splinters, sharp objects | suitable | max. circumferential speed m/s | 4(2) | Model series | FS.. |
| Contents | 1 piece | Customs tariff weight Pro | 1 | Use during maintenance | suitable |
| Use with dust | less suitable | Engineering material | Felt | Customs tariff article number | 59119010 |
| Use with fine particles | less suitable | Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
