INA Two-Bolt Square Flange Units, Gray Cast Iron, Eccentric Locking Collar, P Seal
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Shaft Bore Dia. d (mm) | Basic Load Rating, Dynamic Rating (N) | Basic Load Rating, Static Rating (N) | B1 (mm) | Housing | d3 max. (mm) | Customs tariff weight (kg) | Unit height H (mm) | Center hole distance J (mm) | Unit code | Unit width A (mm) | Unit length L (mm) | A1 (mm) | Bearing code | Model series | Protection cap | A2 (mm) | U (mm) | V (mm) | Width/diameter of fixing hole N (mm) | Product code | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
27.66 € | 1 | 5 Days | 20 | 12800 | 6600 | 31 | GLCTE04 | 33 | 0.47 | 90.5 | 71.4 | GG.GLCTE04-E | - | 66.5 | 17 | GRAE20-NPP-B | GLCTE.. | - | 9.5 | 33 | - | 9 | GLCTE20-XL | |||
31.08 € | 1 | 5 Days | 25 | 14000 | 7800 | 31 | GLCTE05 | 37.5 | 0.47 | 97 | 76.2 | GG.GLCTE05-E | - | 71 | 17.5 | GRAE25-NPP-B | GLCTE.. | - | 9.9 | 33.4 | - | 9 | GLCTE25-XL | |||
36.95 € | 1 | 5 Days | 30 | 19500 | 11300 | 35.8 | GLCTE06 | 44 | 0.75 | 112.5 | 90.5 | GG.GLCTE06-E | - | 84 | 20.5 | GRAE30-NPP-B | GLCTE.. | - | 11.4 | 38.1 | - | 11.5 | GLCTE30-XL | |||
43.42 € | 1 | 5 Days | 35 | 25500 | 15300 | 39 | GLCTE07 | 51 | 1.02 | 126 | 100 | GG.GLCTE07 | - | 94 | 22 | GRAE35-NPP-B | GLCTE.. | - | 12.4 | 41.8 | - | 11.5 | GLCTE35-XL | |||
26.26 € | 1 | 5 Days | 15 | 9800 | 4750 | 28.6 | CFT03 | 28 | 0.34 | 99 | 76.5 | GG.CFT03 | 18 | 57 | 9.5 | GRAE15-NPP-B | PCFT.. | - | - | 32.1 | 57 | 11.5 | PCFT15-XL | |||
27.66 € | 1 | 5 Days | 20 | 12800 | 6600 | 31 | CFT04 | 33 | 0.39 | 112 | 90 | GG.CFT04 | 17.5 | 61 | 10 | GRAE20-NPP-B | PCFT.. | - | - | 34 | 61 | 11.5 | PCFT20-XL | |||
31.31 € | 1 | 5 Days | 25 | 14000 | 7800 | 31 | CFT05 | 37.5 | 0.55 | 124 | 99 | GG.CFT05 | 20 | 70 | 11 | GRAE25-NPP-B | PCFT.. | - | - | 36 | 70 | 11.5 | PCFT25-XL | |||
37.15 € | 1 | 5 Days | 30 | 19500 | 11300 | 35.8 | CFT06 | 44 | 0.77 | 142 | 116.5 | GG.CFT06 | 22.3 | 80 | 12 | GRAE30-NPP-B | PCFT.. | - | - | 40 | 80 | 11.5 | PCFT30-XL | |||
43.69 € | 1 | 5 Days | 35 | 25500 | 15300 | 39 | CFT07 | 51 | 1.06 | 155 | 130 | GG.CFT07 | 25 | 92 | 12.5 | GRAE35-NPP-B | PCFT.. | - | - | 44.9 | 92 | 14 | PCFT35-XL | |||
50.91 € | 1 | 5 Days | 40 | 32500 | 19800 | 43.8 | CFT08 | 58 | 1.45 | 172 | 143.5 | GG.CFT08 | 28.8 | 105 | 13 | GRAE40-NPP-B | PCFT.. | - | - | 51 | 105 | 14 | PCFT40-XL | |||
60.65 € | 1 | 5 Days | 45 | 32500 | 20400 | 43.8 | CJT09 | 63 | 1.79 | 180 | 148.5 | GG.CJT09-N | 35 | 111 | 14 | GRAE45-NPP-B | PCJT.. | - | 24 | 56.7 | 111 | 14 | PCJT45-XL | |||
50.63 € | 1 | 5 Days | 40 | 32500 | 19800 | 43.8 | GLCTE08 | 58 | 1.27 | 150 | 119 | GG.GLCTE08 | - | 100 | 24 | GRAE40-NPP-B | GLCTE.. | - | 13.5 | 46.3 | - | 14 | GLCTE40-XL | |||
25.14 € | 1 | 5 Days | 20 | 12800 | 6600 | 31 | CJT04 | 33 | 0.44 | 112 | 90 | GG.CJT04-N | 28 | 61 | 10 | GRAE20-NPP-B | PCJT.. | KASK04 | 19 | 42.5 | 61 | 11.5 | PCJT20-XL-N | |||
| - | 28.46 € | 1 | 5 Days | 25 | 14000 | 7800 | 31 | - | 37.5 | 0.58 | 124 | 99 | GG.CJT05-N | 26.5 | 70 | 11 | GRAE25-NPP-B | PCJT.. | KASK05 | 19 | 42.5 | 70 | 11.5 | - | ||
33.77 € | 1 | 5 Days | 30 | 19500 | 11300 | 35.8 | CJT06 | 44 | 0.83 | 142 | 116.5 | GG.CJT06-N | 29 | 80 | 11.5 | GRAE30-NPP-B | PCJT.. | KASK06 | 20 | 46.7 | 80 | 11.5 | PCJT30-XL-N | |||
39.72 € | 1 | 5 Days | 35 | 25500 | 15300 | 39 | CJT07 | 51 | 1.13 | 155 | 130 | GG.CJT07-N | 30.5 | 92 | 12.5 | GRAE35-NPP-B | PCJT.. | KASK07 | 21 | 50.5 | 92 | 14 | PCJT35-XL-N | |||
50.91 € | 1 | 5 Days | 40 | 32500 | 19800 | 43.8 | CJT08 | 58 | 1.57 | 172 | 143.5 | GG.CJT08-N | 34.5 | 105 | 14 | GRAE40-NPP-B | PCJT.. | KASK08 | 24 | 56.7 | 105 | 14 | PCJT40-XL-N | |||
68.22 € | 1 | 5 Days | 50 | 35000 | 23200 | 43.8 | CJT10 | 69 | 1.97 | 190 | 157 | GG.CJT10-N | 39 | 116 | 18 | GRAE50-NPP-B | PCJT.. | KASK10 | 28 | 60.7 | 116 | 18 | PCJT50-XL-N | |||
109.02 € | 1 | 5 Days | 60 | 52000 | 36000 | 53.1 | CJT12 | 84 | 3.48 | 238 | 202 | GG.CJT12-N | 46 | 138 | 18 | GRAE60-NPP-B | PCJT.. | KASK12 | 34 | 73.6 | 138 | 18 | PCJT60-XL-N |
Loading...
Basic information
| Bearing Unit, Type | Round Flange Type | Unit Body Material | Cast Iron | Customs tariff goods number | 84832000 |
|---|---|---|---|---|---|
| Method of fixing | Eccentric locking collar | Number of fixing holes | 2 | Customs tariff weight unit | kg |
| Hole shape | cylindrical | Unit material | Gray cast iron | Model | oval |
| Thread | M6 | Relubrication possible yes/no | yes | Customs tariff weight per | 1 |
| Customs tariff country of origin | DE |
Configure
Basic Attributes
-
Shaft Bore Dia. d(mm)
-
B1(mm)
-
Housing
-
d3 max.(mm)
-
Customs tariff weight(kg)
-
Unit height H(mm)
-
Center hole distance J(mm)
-
Unit code
-
Unit width A(mm)
-
Unit length L(mm)
-
A1(mm)
-
Bearing code
-
Model series
-
Protection cap
-
A2(mm)
-
U(mm)
-
V(mm)
-
Width/diameter of fixing hole N(mm)
-
Type
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
