PARKER Parkrimp No-Skive Fitting 19243
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 19243-6-6 |
| 19243-8-8 |
| 19243-12-12 |
| 19243-16-16 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Nominal Dia. (mm) | A (mm) | Thread or tube size | W | B (mm) | Operating pressure Mpa | Hose fitting size | Thread diameter BSP | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
26.37 € | 1 | 3 Days | 10 | 49 | -06 | 22 | 20 | 55 | -06 | 3/8x19 | ||
36.34 € | 1 | 3 Days | 12 | 57 | -08 | 27 | 22 | 43 | -08 | 1/2x14 | ||
59.98 € | 1 | 72 Days | 19 | 61 | -12 | 32 | 22 | 42 | -12 | 3/4x14 | ||
109.17 € | 1 | 72 Days | 25 | 72 | -16 | 41 | 25 | 42 | -16 | 1x11 |
Loading...
Basic information
| Customs tariff weight(kg) | 0 | Customs tariff weight unit | kg | Steel | Galvanized steel, Cr(VI)-free |
|---|---|---|---|---|---|
| Connection group | BSP | Norm | BS5200-A | Common name | DKR |
| Description of connection type | Sealing head with BSP union nut | Connection type | 92 | Fitting series | 43 |
| Customs tariff item number | 73269098 | Customs tariff weight per | 1 | Fitting | Parkrimp fitting |
| Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
