Radial insert ball bearings / single row / outer ring spherical / eccentric locking collar / INA
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 0008518090000 |
| 0008518920000 |
| 0008521550000 |
| 0008523330000 |
| Part Number | Related to |
Standard Unit Price
| Minimum order quantity | Volume Discount | Inner Diameter d (φ) | Outer Diameter D (φ) | Width B (or T) (mm) | Basic Dynamic Load Rating (N) | Maximum Allowable Rotational Speed (1/min) | Basic Load Rating Static Rating (N) | Shoulder dimension d3 (mm) | C2 (mm) | Shoulder dimension d1 (mm) | Threaded pin width across flats | Lubrication hole Ca (mm) | Width C (mm) | Width with mounting components B1 (mm) | Central length S (mm) | Shoulder dimension D1 (mm) | Customs tariff — weight (kg) | Product code | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
27.00 € | 1 | 5 Days | 20 | 47 | 34.1 | 12800 | 18700 | 6600 | 33 | 16.6 | 27.6 | 3 | 4 | 14 | 43.7 | 17.1 | 37.4 | 0.2 | GE20-XL-KLL-B | |||
30.77 € | 1 | 5 Days | 25 | 52 | 34.9 | 14000 | 16700 | 7800 | 37.5 | 20.2 | 33.8 | 3 | 3.9 | 15 | 44.5 | 17.5 | 42.5 | 0.25 | GE25-XL-KLL-B | |||
44.32 € | 1 | 5 Days | 40 | 80 | 42.9 | 34500 | 10300 | 19800 | 58 | 28.1 | 52.3 | 5 | 6.4 | 21 | 56.5 | 21.4 | 68.3 | 0.75 | GE40-XL-KLL-B | |||
56.83 € | 1 | 5 Days | 50 | 90 | 49.2 | 37500 | 9000 | 23200 | 69 | 26.4 | 62.8 | 5 | 6.9 | 22 | 62.8 | 24.6 | 77.3 | 1 | GE50-XL-KLL-B |
Loading...
Basic information
| Load Direction | Radial | Size Standard | Metric System | Product type | Radial insert ball bearing |
|---|---|---|---|---|---|
| Ring nut | No | Bore shape | Cylindrical | Designator cover / seal | Two zinc-plated, outward angled sheet steel washers in outer ring with a zinc-plated sheet steel angle ring pressed onto the inner ring |
| Method of attachment | Eccentric locking collar | Marking cover / seal | KLL | Rotation direction | Constant |
| Model series | GE.. | Outer surface design | Spherical | Engineering material | Steel |
| Customs tariff — weight per | 1 | Customs tariff — weight unit | kg | Customs tariff — item number | 84821090 |
| Customs tariff — country of origin | DE |
Configure
Basic Attributes
-
Inner Diameter d(φ)
-
Outer Diameter D(φ)
-
Width B (or T)(mm)
-
Basic Dynamic Load Rating(N)
-
Shoulder dimension d3(mm)
-
C2(mm)
-
Shoulder dimension d1(mm)
-
Threaded pin width across flats
-
Lubrication hole Ca(mm)
-
Width C(mm)
-
Width with mounting components B1(mm)
-
Central length S(mm)
-
Shoulder dimension D1(mm)
-
Customs tariff — weight(kg)
-
Type
-
Filter by CAD data type
- 3D
Filter by standard shipping days
-
- All
- 5 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
