HYDAC Directional Poppet Valve WSM08130D
[Specifications]
・Valve type: Directional poppet valve
・Type: WSM08130D
・Maximum operating pressure (bar): 350
[Features]
・Very low Leckage in directional valves poppet style
・Optimal value for money
・Large variety of symbols
・Valve type: Directional poppet valve
・Type: WSM08130D
・Maximum operating pressure (bar): 350
[Features]
・Very low Leckage in directional valves poppet style
・Optimal value for money
・Large variety of symbols
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 3229128 |
| 3229152 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Customs tariff weight (kg) | Voltage (V/Hz) | Ambient temperature range | Electrical connection | |
|---|---|---|---|---|---|---|---|---|
421.54 € | 1 | 5 Days | 0.2 | Without coil | -20°C to +60°C | None | ||
509.23 € | 1 | 5 Days | 0.49 | DC 24 V | -20°C to +60 °C | With component plug according to DIN EN 175301-803, without plug-in connector (ordered separately) |
Loading...
Basic information
| Maximum flow rate(l/min) | 22 | Spool position | Not monitored | Screw-in bore | M 20x1.5 _ 08130 |
|---|---|---|---|---|---|
| Valve type | Directional poppet valve | Version | Screw-in valve | Customs tariff weight unit | kg |
| Actuation type | Direct-operated | Spring return | With spring return | Home position | Flow from port 1 to port 2 |
| Main connections | 3 | Spool symbol | D | Maximum operating pressure(bar) | 350 |
| Actuation | Electrical | Type | WSM08130D | Hydraulic fluid temperature range | -20°C to +100°C |
| Auxiliary actuation device | Without auxiliary actuation device | Leakage | Free from leakage oil (max. 5 drops/min at 350 bar) | Customs tariff item number | 84812010 |
| Customs tariff weight per | 1 | Throttle insert diameter(mm) | None | Customs tariff country of origin | DE |
| Sealing material | NBR |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
