NILOS Ring JVG
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 7204JVG |
| 7205JVG |
| 7206JVG |
| 7211JVG |
| 7213JVG |
| 7215JVG |
| 7305JVG |
| 7306JVG |
| 7308JVG |
| 7309JVG |
| 7310JVG |
| 7311JVG |
| Part Number | Minimum order quantity | Volume Discount | Customs tariff weight (kg) | Outside diameter D (mm) | Thickness s (mm) | Roller bearing designation | Internal diameter d (mm) | |
|---|---|---|---|---|---|---|---|---|
| 2 | 5 Days | 0.003 | 47 | 2 | 7204 | 23.2 | ||
| 2 | 5 Days | 0.004 | 52 | 2.5 | 7205 | 28 | ||
| 2 | 5 Days | 0.006 | 62 | 2.5 | 7206 | 33 | ||
| 2 | 5 Days | 0.013 | 100 | 3 | 7211 | 60 | ||
| 2 | 5 Days | 0.019 | 120 | 3 | 7213 | 72.5 | ||
| 2 | 5 Days | 0.033 | 130 | 3.5 | 7215 | 81 | ||
| 2 | 5 Days | 0.006 | 62 | 2.5 | 7305 | 30 | ||
| 2 | 5 Days | 0.008 | 72 | 2.5 | 7306 | 37.2 | ||
| 2 | 5 Days | 0.012 | 90 | 3 | 7308 | 47.5 | ||
| 2 | 5 Days | 0.014 | 100 | 3 | 7309 | 52.3 | ||
| 2 | 5 Days | 0.018 | 110 | 3 | 7310 | 57.5 | ||
| 2 | 5 Days | 0.022 | 120 | 3 | 7311 | 64 |
Loading...
Basic information
| Design | JVG | Customs tariff weight unit | kg | Type | NILOS ring |
|---|---|---|---|---|---|
| Customs tariff weight Pro | 1 | Engineering material | Zinc-plated special strip steel | Customs tariff article number | 73269098 |
| Customs tariff country of origin | DE |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
