Deep groove ball bearings / single row / seals on both sides / tapered bore / SKF
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 6208-2RS1K |
| 6209-2RS1K |
| 6210-2RS1K |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. D (φ) | Outer Diameter D (φ) | Width B (mm) | Maximum Allowable Rotational Speed (1/min) | Basic Load Rating Static Rating (N) | Basic Load Rating Dynamic Rating (Ca) (N) | Customs tariff — weight (kg) | Shoulder dimension d1 (mm) | Fatigue limit load Pu (kN) | Bore code | Shoulder dimension D1 (mm) | Reference speed rpm | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
26.23 € | 1 | 5 Days | 40 | 80 | 18 | 5600 | 19000 | 32500 | 0.362 | 52.6 | 0.8 | 08 | 69.8 | 18,000 | ||
34.68 € | 1 | 5 Days | 45 | 85 | 19 | 5000 | 21600 | 35100 | 0.415 | 57.6 | 0.915 | 09 | 75.5 | 17,000 | ||
62.66 € | 1 | 5 Days | 50 | 90 | 20 | 4800 | 23200 | 37100 | 0.458 | 62.5 | 0.98 | 10 | 81.7 | - |
Loading...
Basic information
| Number of Bearing Ring Rows | Single Row | Size Standard | Metric System | Design | Deep-groove ball bearing |
|---|---|---|---|---|---|
| Ring nut | No | r (min.)(mm) | 1.1 | Customs tariff — weight per | 1 |
| Bore shape | Tapered | Customs tariff — weight unit | kg | Designator cover / seal | Contact gasket on both sides, NBR |
| Customs tariff — item number | 84821090 | Marking cover / seal | 2RS1 | Model series | 62.. |
| Customs tariff — country of origin | DE | Engineering material | Steel | Bearing clearance identifier | CN |
| Cage material | Sheet steel | Flange on outer ring | No | Norm | DIN 625 |
| Bearing clearance designator | Normal radial clearance |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
