PARKER WH-R High Pressure Elbow Swivel Screw Fitting
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| WH06LRCF |
| WH06SRCF |
| WH08SRCF |
| WH10LRCF |
| WH10SRCF |
| WH12LRCF |
| WH12SRCF |
| WH15LRCF |
| WH16SRCF |
| WH18LRCF |
| WH20SRCF |
| WH22LRCF |
| WH25SRCF |
| WH28LRCF |
| Part Number | Minimum order quantity | Volume Discount | S2 (mm) | D4 | L5 | L7 | PN bar | Customs tariff weight (kg) | External pipe diameter D1 | L4 | S1 | L2 | L3 | L1 | D3 | Model series | T | L6 | S3 | D5 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | 5 Days | 17 | 4.5 | 24 | 2.5 | 250 | 0.064 | 6 | 8 | 17 | 12 | 10.5 | 19 | 4 | L | G 1/8 A | 27 | 14 | 14 | ||
| 1 | 5 Days | 19 | 6 | 30 | 3 | 315 | 0.122 | 6 | 12 | 22 | 16.5 | 14 | 23.5 | 4 | S | G 1/4 A | 31 | 17 | 18 | ||
| 1 | 5 Days | 19 | 6 | 30 | 3 | 315 | 0.127 | 8 | 12 | 22 | 16.5 | 14 | 23.5 | 5 | S | G 1/4 A | 31 | 19 | 18 | ||
| 1 | 5 Days | 19 | 6 | 30 | 3 | 250 | 0.124 | 10 | 12 | 22 | 15.5 | 14 | 22.5 | 8 | L | G 1/4 A | 30 | 19 | 18 | ||
| 1 | 5 Days | 24 | 7.5 | 36 | 3 | 315 | 0.206 | 10 | 12 | 27 | 18.5 | 16.5 | 26 | 7 | S | G 3/8 A | 35 | 22 | 22 | ||
| 1 | 5 Days | 24 | 7.5 | 36 | 3 | 250 | 0.194 | 12 | 12 | 27 | 18 | 16.5 | 25 | 10 | L | G 3/8 A | 33 | 22 | 22 | ||
| 1 | 5 Days | 24 | 7.5 | 36 | 3 | 315 | 0.211 | 12 | 12 | 27 | 18.5 | 16.5 | 26 | 8 | S | G 3/8 A | 35 | 24 | 22 | ||
| 1 | 5 Days | 30 | 11 | 45 | 4.5 | 250 | 0.345 | 15 | 14 | 32 | 21.5 | 21.5 | 28.5 | 12 | L | G 1/2 A | 37 | 27 | 26 | ||
| 1 | 5 Days | 30 | 11 | 45 | 4.5 | 315 | 0.389 | 16 | 14 | 32 | 22 | 21.5 | 30.5 | 12 | S | G 1/2 A | 40 | 30 | 26 | ||
| 1 | 5 Days | 30 | 11 | 45 | 4.5 | 250 | 0.374 | 18 | 14 | 32 | 21 | 21.5 | 28.5 | 15 | L | G 1/2 A | 37 | 32 | 26 | ||
| 1 | 5 Days | 36 | 17 | 53 | 3.5 | 160 | 0.649 | 20 | 16 | 41 | 26.5 | 24 | 37 | 16 | S | G 3/4 A | 48 | 36 | 32 | ||
| 1 | 5 Days | 36 | 17 | 53 | 3.5 | 160 | 0.601 | 22 | 16 | 41 | 27.5 | 24 | 35 | 19 | L | G 3/4 A | 44 | 36 | 32 | ||
| 1 | 5 Days | 46 | 21 | 66 | 3.5 | 160 | 1.17 | 25 | 18 | 50 | 31.5 | 30.5 | 43.5 | 20 | S | G 1 A | 56 | 46 | 39 | ||
| 1 | 5 Days | 46 | 21 | 66 | 3.5 | 160 | 1.065 | 28 | 18 | 50 | 32 | 30.5 | 39.5 | 24 | L | G 1 A | 49 | 41 | 39 |
Loading...
Basic information
| Customs tariff weight unit | kg | Scope of delivery | Complete, with nut and ring | Order code | WH-R |
|---|---|---|---|---|---|
| Surface | Cr(VI)-free | Customs tariff item number | 73079290 | Engineering material | Steel |
| Customs tariff weight per | 1 | Customs tariff country of origin | DE |
