Configure
- Inner Diameter(mm)
- 42.7
- 47.7
- 57.7
- 73.7
- 78.2
- 118.2
- 138.2
- 144.7
- 157.7
- 184.2
- Outer Diameter(mm)
- 42.7
- 47.7
- 57.7
- 73.7
- 78.2
- 118.2
- 138.2
- 144.7
- 157.7
- 184.2
- Width(mm)
- 17
- 19.5
- 22.63
- 23
- 24.625
- 27.125
- Customs tariff weight(kg)
- 0.074
- 0.085
- 0.098
- 0.11
- 0.14
- 0.167
- 0.172
- 0.211
- 0.444
- 0.73
- 1.148
- 1.947
- 2.126
- Type
- Est. shipping days
- All
- Within 3 working days
- Within 4 working days
Labyrinth Seal TSV, Material: Steel, FKM
Part number:
possible part numbers found.Part number list
Number of items
Unit price (excluding VAT)(Unit price including VAT) | Standard shipping days |
|---|
40.07 € ( 47.68 € ) | 4 working days |
41.38 € ( 49.24 € ) | 4 working days |
44.82 € ( 53.34 € ) | 3 working days |
57.85 € ( 68.84 € ) | 4 working days |
63.90 € ( 76.04 € ) | 4 working days |
90.30 € ( 107.46 € ) | 4 working days |
94.57 € ( 112.54 € ) | 3 working days |
126.05 € ( 150.00 € ) | 4 working days |
46.67 € ( 55.54 € ) | 4 working days |
51.88 € ( 61.74 € ) | 4 working days |
53.27 € ( 63.39 € ) | 4 working days |
110.92 € ( 131.99 € ) | 4 working days |
113.67 € ( 135.27 € ) | 4 working days |
More Information
Basic information
[Specifications]
・Material: Steel, FKM
・Inner Diameter(mm): 42.7~184.2
・Outer Diameter(mm): 42.7~184.2
Labyrinth seals TSV give non-contact sealing. They are therefore suitable for high circumferential velocities. The O ring, which is pressed between the labyrinth ring and shaft, is made from fluoro rubber FKM and is suitable for temperatures of up to +200 °C. The labyrinth seal allows shaft misalignment of up to 0,5° in both directions.
