Needle Bush
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| BK 0509 |
| BK 0609 |
| BK 0709 |
| BK 0808 |
| BK 0912 |
| BK 1010 |
| BK 1012 |
| BK 1015 |
| BK 1210 |
| BK 1212 |
| BK 1512 |
| BK 1516 |
| BK 1616 |
| BK 2016 |
| BK 2520 |
| BK 2526 |
| BK 3020 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | I.D. d (mm) | O.D. D (mm) | Width B (mm) | Weight (g) | GTIN/EAN | |
|---|---|---|---|---|---|---|---|---|---|
4.55 € | 1 | 12 Days | 5 | 9 | 9 | 2.0 | 7316570032369 | ||
3.54 € | 1 | 17 Days | 6 | 10 | 9 | 3.0 | 7316570189247 | ||
3.56 € | 1 | 17 Days | 7 | 11 | 9 | 3.0 | 7316570116038 | ||
3.62 € | 1 | 17 Days | 8 | 12 | 8 | 3.0 | 7316570167313 | ||
3.66 € | 1 | 17 Days | 9 | 13 | 12 | 5.0 | 7316571143071 | ||
3.66 € | 1 | 17 Days | 10 | 14 | 10 | 4.0 | 7316570709186 | ||
4.48 € | 1 | 17 Days | 10 | 14 | 12 | 5.0 | 7316570035292 | ||
5.08 € | 1 | 17 Days | 10 | 14 | 15 | 6.0 | 7316570602586 | ||
3.89 € | 1 | 17 Days | 12 | 16 | 10 | 5.0 | 7316571106519 | ||
5.32 € | 1 | 17 Days | 12 | 18 | 12 | 10.0 | 7316570472639 | ||
4.96 € | 1 | 17 Days | 15 | 21 | 12 | 13.0 | 7316570382952 | ||
5.06 € | 1 | 17 Days | 15 | 21 | 16 | 17.0 | 7316570957860 | ||
4.72 € | 1 | 17 Days | 16 | 22 | 16 | 18.0 | 7316570124224 | ||
6.05 € | 1 | 17 Days | 20 | 26 | 16 | 22.0 | 7316571153704 | ||
7.21 € | 1 | 17 Days | 25 | 32 | 20 | 39.0 | 7316570642209 | ||
7.52 € | 1 | 17 Days | 25 | 32 | 26 | 49.0 | 7316570437140 | ||
8.03 € | 1 | 17 Days | 30 | 37 | 20 | 47.0 | 7316570938081 |
Loading...
Basic information
| temperature range in °C, up to | 140 °C | cage material | steel plate | series | BK |
|---|---|---|---|---|---|
| Customs tariff number | 84824000 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
