U-ring, Piston, 80NBR878
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Outer Diameter (mm) | Internal Diameter (φ) | Groove length (mm) | Width (mm) | Series | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|
129.74 € | 1 | Available | 17 Days | 140 | 115 | 16 | 15 | NA 250 | 78 | |
44.76 € | 1 | Available | 17 Days | 40 | 25 | 11 | 10 | NA 250 | 7.601 | |
47.69 € | 1 | Available | 17 Days | 50 | 35 | 11 | 10 | NA 250 | 10.95 | |
48.77 € | 1 | Available | 17 Days | 55 | 40 | 11 | 10 | NA 250 | 12.25 | |
49.86 € | 1 | Available | 17 Days | 60 | 45 | 11 | 10 | NA 250 | 10 | |
51.69 € | 1 | Available | 17 Days | 63 | 45 | 13 | 12 | NA 250 | 18.5 | |
53.91 € | 1 | Available | 17 Days | 70 | 55 | 13 | 12 | NA 250 | 20 | |
56.01 € | 1 | Available | 17 Days | 80 | 65 | 13 | 12 | NA 250 | 23 | |
56.01 € | 1 | Available | 17 Days | 80 | 60 | 13 | 12 | NA 250 | 27.891 | |
75.37 € | 1 | Available | 17 Days | 90 | 75 | 13 | 12 | NA 250 | 26.331 | |
85.22 € | 1 | Available | 17 Days | 100 | 80 | 16 | 15 | NA 250 | 49.211 | |
88.48 € | 1 | Available | 17 Days | 105 | 85 | 16 | 15 | NA 250 | 51 | |
34.61 € | 1 | Available | 17 Days | 50 | 30 | 13 | 12 | NA 400 | 15.701 | |
37.50 € | 1 | Available | 12 Days | 63 | 48 | 11 | 10 | NA 400 | 13.601 | |
42.00 € | 1 | Available | 17 Days | 80 | 65 | 11 | 10 | NA 400 | 17.801 | |
42.00 € | 1 | Available | 12 Days | 80 | 60 | 13 | 12 | NA 400 | 30 | |
63.91 € | 1 | Available | 17 Days | 100 | 80 | 13 | 12 | NA 400 | 35.401 | |
79.40 € | 1 | Available | 17 Days | 125 | 105 | 13 | 12 | NA 400 | 44.501 | |
103.98 € | 1 | Available | 17 Days | 160 | 135 | 16 | 15 | NA 400 | 87.101 | |
148.55 € | 1 | Available | 17 Days | 200 | 175 | 16 | 15 | NA 400 | 108.301 | |
66.53 € | 1 | Available | 12 Days | 110 | 90 | 13 | 12 | NA 400 | 37.401 | |
122.32 € | 1 | Available | 17 Days | 180 | 150 | 19 | 18 | NA 400 | 144.3 | |
12.53 € | 1 | Available | 12 Days | 12 | 6 | 4.5 | 4 | NA 150 | 0.411 | |
12.53 € | 1 | Available | 12 Days | 16 | 10 | 4.5 | 4 | NA 150 | 0.491 | |
12.43 € | 1 | Available | 12 Days | 20 | 12 | 6 | 5.5 | NA 150 | 1.101 | |
12.86 € | 1 | Available | 12 Days | 25 | 17 | 6 | 5.5 | NA 150 | 1.6 | |
13.43 € | 1 | Available | 12 Days | 32 | 24 | 6 | 5.5 | NA 150 | 2 | |
13.52 € | 1 | Available | 12 Days | 40 | 30 | 7.5 | 7 | NA 150 | 4.011 | |
14.41 € | 1 | Available | 17 Days | 50 | 40 | 7.5 | 7 | NA 150 | 5.121 | |
16.15 € | 1 | Available | 12 Days | 63 | 53 | 7.5 | 7 | NA 150 | 6.751 | |
16.85 € | 1 | Available | 12 Days | 70 | 58 | 9.5 | 8.5 | NA 150 | 10.57 | |
17.51 € | 1 | Available | 12 Days | 80 | 68 | 9.5 | 8.5 | NA 150 | 12.141 | |
26.62 € | 1 | Available | 12 Days | 100 | 88 | 9.5 | 8.5 | NA 150 | 15.391 | |
34.20 € | 1 | Available | 17 Days | 125 | 110 | 11 | 10 | NA 150 | 28.8 | |
40.54 € | 1 | Available | 12 Days | 140 | 125 | 11 | 10 | NA 150 | 32.441 | |
50.97 € | 1 | Available | 17 Days | 180 | 160 | 15 | 14 | NA 150 | 77.301 | |
61.90 € | 1 | Available | 17 Days | 200 | 180 | 15 | 14 | NA 150 | 86.6 | |
33.53 € | 1 | Available | 17 Days | 45 | 30 | 11 | 10 | NA 400 | 9.4 | |
35.39 € | 1 | Available | 17 Days | 55 | 40 | 11 | 10 | NA 400 | 10.4 | |
39.11 € | 1 | Available | 17 Days | 70 | 50 | 13 | 12 | NA 400 | 23.701 |
Loading...
Basic information
| Hardness in Shore | 80 | Material | NBR | Customs tariff number | 40169300 |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
