Flow Control Valves
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| T1000C1800 |
| T1000C2800 |
| T1000C3800 |
| T1000C4800 |
| T1000M0500 |
| T1100C1800 |
| T1100C2800 |
| T1100C4800 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Operating Pressure Range (Bar) | Range | Operating Pressure Range (psi) | Seat Seal | Flow (l/min) | Thread Type | Operating Temperature Range (Fahrenheit) | Function | Port Size | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
28.76 € | 1 | 5 Days | 1 - 10 | T1000 | 15 - 145 | - | 0.37 | - | 0 - 175 | - | G1/8 | ||
32.76 € | 1 | 5 Days | 1 - 10 | T1000 | 15 - 145 | - | 0.69 | - | 0 - 175 | - | G1/4 | ||
54.40 € | 1 | 5 Days | 1 - 10 | T1000 | 15 - 145 | - | 1.64 | - | 0 - 175 | - | G3/8 | ||
67.49 € | 1 | 5 Days | 1 - 10 | T1000 | 15 - 145 | - | 2 | - | 0 - 175 | - | G1/2 | ||
33.09 € | 1 | 5 Days | 0.3 - 10 | T1000 | 5 - 145 | - | 0.07 | Metric | 0 - 175 | - | M5 | ||
39.05 € | 1 | 5 Days | 0 - 10 | T1100 | - | Nitrile rubber | - | - | - | Bi-directional | G1/8 | ||
39.15 € | 1 | 5 Days | 0 - 10 | T1100 | - | Nitrile rubber | - | - | - | Bi-directional | G1/4 | ||
125.02 € | 1 | 5 Days | 0 - 10 | T1100 | - | Nitrile rubber | - | - | - | Bi-directional | G1/2 |
Loading...
Basic information
| Operating Temperature Range(°C) | -20 - 80 | Body | Aluminium |
|---|
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
