Stainless Steel-Retaining magnets, female thread

Stainless Steel-Retaining magnets, female thread

Part number:

Still undefined. 5 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    50.25-HF-25-7-M5
    50.25-HF-32-7-M5
    50.25-HF-40-8-M5
    50.25-HF-50-10-M5
    50.25-HF-63-14-M5

    h

    d1_1

    Diameter d1

    Nennhaftkräfte [N]

    Weight

    (g)

    Länge l

    h_1

    t

    		Minimum order quantity
    7
    ±0.1
    25
    32. 32
    20.0
    9
    +0.3/-0.2
    8.25
    1 pieces
    7
    ±0.1
    32
    64. 64
    31.0
    9
    +0.3/-0.2
    9
    1 pieces
    8
    +0.2/-0.1
    40
    100. 100
    56.0
    8.5
    +0.3/-0.2
    9
    1 pieces
    10
    +0.2/-0.1
    50
    175. 175
    105.0
    8.5
    +0.4/-0.2
    9
    1 pieces
    14
    +0.3/-0.1
    63
    280. 280
    228.0
    8
    +0.5/-0.2
    9
    1 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    6.08 €
    ( 7.24 € )
    7 working days
    6.92 €
    ( 8.23 € )
    7 working days
    8.20 €
    ( 9.76 € )
    7 working days
    10.02 €
    ( 11.92 € )
    7 working days
    15.62 €
    ( 18.59 € )
    7 working days
  • 1

    • More Information

    Basic information

    [Specifications]
    ・Material: HF. Hard ferrite
    ・Thread: M5
    ・D3: 8
    ・h: 7-14

    Stainless steel retaining magnets GN 50.25 are combined with the stainless steel housing and the plastic ring into a system that shields and strengthens the magnet for optimal transmission of the magnetic flux onto the magnetic surface.
