Pressed Steel Fixed Castor, B-VWPP Series
Bracket: B series
- pressed steel, zinc-plated, blue-passivated, Cr6-free
Wheel: VWPP series
- tyre: soft rubber "Blickle Soft", hardness 50 Shore A, colour black (wheel Ø 260 mm with additional hard rubber core)
- rim: high-quality polypropylene, impact resistant, colour black
- high chemical resistance to many aggressive substances, except oils
- operating temperature: -20 °C to +60 °C, reduced load capacity over +30 °C
- wheel Ø 260 mm with additional hard rubber core
- puncture-proof alternatives for pneumatic tyres
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Mounting Height H (mm) | Load Range (daN) | Wheel Characteristics | Plate Length L (mm) | Plate Width W (mm) | Wheel Dia. D (mm) | Wheel Width B (mm) | Bearing type | Total height (mm) | Weight (g) | Wheel diameter (mm) | Wheel width (mm) | Tread color | Non-staining | Non-marking | Load capacity at 4 km/h (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
30.02 € | 1 | 7 Days | 150 | 35.01 to 80.00 | - | 100 | 85 | 125 | 38 | plain bore | 150 | 756 | 125 | 38 | black | no | no | 50 | ||
37.60 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | plain bore | 150 | 780 | 125 | 38 | black | no | no | 50 | ||
33.23 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | plain bore | 150 | 774 | 125 | 38 | grey | yes | yes | 50 | ||
40.80 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | plain bore | 150 | 795 | 125 | 38 | grey | yes | yes | 50 | ||
34.20 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | roller bearing | 150 | 784 | 125 | 38 | black | no | no | 50 | ||
41.78 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | roller bearing | 150 | 822 | 125 | 38 | black | no | no | 50 | ||
37.40 € | 1 | 23 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | roller bearing | 150 | 808 | 125 | 38 | grey | yes | yes | 50 | ||
44.98 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 100 | 85 | 160 | 40 | roller bearing | 150 | 827 | 125 | 38 | grey | yes | yes | 50 | ||
49.69 € | 1 | 7 Days | 195 | 35.01 to 80.00 | - | 140 | 110 | 160 | 40 | plain bore | 195 | 1358 | 160 | 40 | black | no | no | 70 | ||
59.37 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | plain bore | 195 | 1410 | 160 | 40 | black | no | no | 70 | ||
57.06 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | plain bore | 195 | 1382 | 160 | 40 | grey | yes | yes | 70 | ||
66.75 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | plain bore | 195 | 1483 | 160 | 40 | grey | yes | yes | 70 | ||
61.32 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | roller bearing | 195 | 1462 | 160 | 40 | black | no | no | 70 | ||
71.00 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | roller bearing | 195 | 1559 | 160 | 40 | black | no | no | 70 | ||
68.70 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | roller bearing | 195 | 1477 | 160 | 40 | grey | yes | yes | 70 | ||
78.38 € | 1 | 7 Days | 235 | 35.01 to 80.00 | - | 140 | 110 | 200 | 50 | roller bearing | 195 | 1565 | 160 | 40 | grey | yes | yes | 70 | ||
65.81 € | 1 | 7 Days | 235 | 80.01 to 140.00 | - | 140 | 110 | 200 | 50 | plain bore | 235 | 1981 | 200 | 50 | black | no | no | 100 | ||
76.85 € | 1 | 7 Days | 308 | 80.01 to 140.00 | - | 140 | 110 | 260 | 85 | plain bore | 235 | 2100 | 200 | 50 | black | no | no | 100 | ||
76.10 € | 1 | 7 Days | 308 | 80.01 to 140.00 | - | 140 | 110 | 260 | 85 | plain bore | 235 | 2024 | 200 | 50 | grey | yes | yes | 100 | ||
87.13 € | 1 | 7 Days | 308 | 80.01 to 140.00 | - | 140 | 110 | 260 | 85 | plain bore | 235 | 2109 | 200 | 50 | grey | yes | yes | 100 | ||
79.40 € | 1 | 7 Days | 125 | 80.01 to 140.00 | - | 140 | 110 | 100 | 32 | roller bearing | 235 | 2068 | 200 | 50 | black | no | no | 100 | ||
90.45 € | 1 | 7 Days | 125 | 80.01 to 140.00 | - | 140 | 110 | 100 | 32 | roller bearing | 235 | 2184 | 200 | 50 | black | no | no | 100 | ||
89.69 € | 1 | 7 Days | 125 | 80.01 to 140.00 | Conductivity | 140 | 110 | 100 | 32 | roller bearing | 235 | 2095 | 200 | 50 | grey | yes | yes | 100 | ||
100.73 € | 1 | 7 Days | 150 | 80.01 to 140.00 | - | 140 | 110 | 125 | 32 | roller bearing | 235 | 2205 | 200 | 50 | grey | yes | yes | 100 | ||
213.98 € | 1 | 7 Days | 150 | 140.01 to 220.00 | - | 220 | 130 | 125 | 32 | plain bore | 308 | 5920 | 260 | 85 | black | no | no | 200 | ||
228.63 € | 1 | 7 Days | 150 | 140.01 to 220.00 | Conductivity | 220 | 130 | 125 | 32 | Ball bearing | 308 | 6089 | 260 | 85 | black | no | no | 200 | ||
215.80 € | 1 | 7 Days | 195 | 140.01 to 220.00 | - | 220 | 130 | 160 | 40 | roller bearing | 308 | 6105 | 260 | 85 | black | no | no | 200 |
Loading...
Basic information
| Caster Type | Plate Type Swivel / Screw-In Type / Through Hole Type / Rotation Type | Wheel Material | Engineering Plastics | Material (details) | Tread material: Rubber, Wheel body material: high-quality polypropylene |
|---|---|---|---|---|---|
| Material | Rubber | Product type | fixed castor | Suitable for autoclaves | no |
| Mounting type | top plate | Tread and tyre hardness | 50 Shore A | Wheel body color | black |
| Tread hydrolysis-resistant | no | Rustproof | no | Maximum temperature resistance(°C) | 60 |
| Minimum temperature resistance(°C) | -20 |
Configure
Basic Attributes
-
Mounting Height H(mm)
-
Load Range(daN)
- 35.01 to 80.00
- 80.01 to 140.00
- 140.01 to 220.00
-
Wheel Characteristics
- Conductivity
-
Plate Length L(mm)
-
Plate Width W(mm)
-
Wheel Dia. D(mm)
-
Wheel Width B(mm)
-
Bearing type
- Ball bearing
- plain bore
- roller bearing
-
Total height(mm)
-
Weight(g)
-
Wheel diameter(mm)
-
Wheel width(mm)
-
Tread color
-
Non-staining
- no
- yes
-
Non-marking
- no
- yes
-
Load capacity at 4 km/h(kg)
-
Type
- B-VWPP
Filter by standard shipping days
-
- All
- 7 Days or Less
- 23 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
