Self-aligning pads, adjustable, with O-ring, exchangeable inserts, hexagon socket, Form F, flattened ball with carbide diamond grip (02009)
· Application sectors: machine and fixture construction, assembly
· Ball secured against rotation
· O-ring for protection against dirt and foreign particles
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 02009-920X030 |
| 02009-920X050 |
| 02009-920X070 |
| 02009-924X040 |
| 02009-924X080 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | B=Thread length (mm) | D2=Thread | D3 (mm) | D4 (mm) | H=Height (mm) | Ball Ø (mm) | SW (mm) | Load rating max. (static load only) (kN) | Order No. gripper | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
101.44 € | 1 | 4 Days | 30 | M20 | 10 | 7.9 | 30 | 13 | 8 | 37 | K0385.10107 | ||
102.78 € | 1 | 4 Days | 50 | M20 | 10 | 7.9 | 50 | 13 | 8 | 37 | K0385.10107 | ||
106.48 € | 1 | 4 Days | 70 | M20 | 10 | 7.9 | 70 | 13 | 8 | 37 | K0385.10107 | ||
122.05 € | 1 | 4 Days | 40 | M24 | 12 | 9.5 | 40 | 15 | 10 | 55 | K0385.12107 | ||
128.95 € | 1 | 4 Days | 80 | M24 | 12 | 9.5 | 80 | 15 | 10 | 55 | K0385.12107 |
Loading...
Basic information
| Main material | High carbon steel | Surface finish body | tempered, black oxidised | Component material | Tool steel |
|---|---|---|---|---|---|
| Surface finish component | hardened and bright | Material (mount surface / support surface) | Carbide | Form | M |
| H1(mm) | 4 | H2(mm) | 10 | SW1(mm) | 10 |
