Spring Plungers with Bolt from Steel, with Internal Hexagon, Strong Spring Tension, Stainless Steel
- Volume Discount
Note:
Used for fixation or as device to press something in or push it out. The spring plungers can be mounted and demounted using the internal hexagon or the slot.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 65499655V |
| 65499656V |
| 65499658V |
| 65499660V |
| 65499662V |
| 65499667V |
| 65499671V |
| 65499674V |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Thread size d1 (mm) | Bolt diameter d2 (mm) | Length l (mm) | n (mm) | Overhang of bolt s (mm) | t (mm) | Wrench size SW (mm) | Spring load inital* F1 (N) | Spring load end* F2 (N) | Weight (g) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10.92 € | 1 | Available | 4 Days | M 5 | 2.4 | 18 | 1.2 | 2.3 | 0.8 | 1.5 | 15 | 44 | 1.6 | |
10.92 € | 1 | Available | 4 Days | M 6 | 2.7 | 20 | 1.3 | 2.5 | 0.9 | 2 | 20 | 50 | 2.8 | |
12.33 € | 1 | Available | 4 Days | M 8 | 3.5 | 22 | 1.5 | 3 | 1.4 | 2.5 | 26 | 70 | 5.7 | |
13.91 € | 1 | Available | 4 Days | M 10 | 4 | 22 | 1.5 | 3 | 1.4 | 3 | 26 | 70 | 9.1 | |
18.40 € | 1 | Available | 4 Days | M 12 | 6 | 28 | 2.7 | 4 | 2 | 4 | 51 | 122 | 16 | |
27.74 € | 1 | Available | 4 Days | M 16 | 7.5 | 32 | 3.2 | 5 | 2.5 | 5 | 72 | 164 | 26 | |
45.45 € | 1 | Available | 4 Days | M 20 | 10 | 40 | 3.7 | 7 | 3 | 6 | 93 | 211 | 67 | |
41.09 € | 1 | Available | 4 Days | M 24 | 12 | 52 | 3.7 | 10 | 3 | 8 | 86 | 247 | 129 |
Loading...
Basic information
| Material | Stainless steel (1.4305) | Surface | Blank |
|---|
Configure
Basic Attributes
-
Thread size d1(mm)
-
Bolt diameter d2(mm)
-
Length l(mm)
-
n(mm)
- 1.2
- 1.3
- 1.5
- 2.7
- 3.2
- 3.7
-
Overhang of bolt s(mm)
- 2.3
- 2.5
- 3
- 4
- 5
- 7
- 10
-
t(mm)
- 0.8
- 0.9
- 1.4
- 2
- 2.5
- 3
-
Wrench size SW(mm)
-
Spring load inital* F1(N)
-
Spring load end* F2(N)
Filter by standard shipping days
-
- All
- 4 Days or Less
Optional Attributes
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
