Trapezoidal thread spindle right-hand thread rolled, double-start, steel or stainless steel (24001)

Trapezoidal thread spindle right-hand thread rolled, double-start, steel or stainless steel (24001)

NORELEM

NORELEM

· Corresponding to the dimensions and requirements of DIN 103

· No separate lock is required in the rest position

· High feed movement

· High precision

· Version: steel or stainless steel

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
24001-060212X1000
24001-120611X1000
24001-120612X1000
24001-160811X1000
24001-160812X1000
24001-200811X1000
24001-200812X1000
24001-241011X1000
24001-241012X1000
24001-301211X1000
24001-301212X1000
24001-401411X1000
24001-401412X1000
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
D1 max. D2 DxP=thread D1 min. Main material Steel code Weight in kg (ERP)
(kg)

84.44 €

1 4 Days 5.4374.461Tr 6x2 P15.287stainless steel1.43010.1800

27.35 €

1 4 Days 10.4157.84Tr 12x6 P310.191mild steel1.04010.6600

75.76 €

1 4 Days 10.4157.84Tr 12x6 P310.191stainless steel1.43010.6590

41.80 €

1 4 Days 13.90510.8Tr 16x8 P413.64mild steel1.04011.1500

119.85 €

1 4 Days 13.90510.8Tr 16x8 P413.64stainless steel1.43011.1700

63.85 €

1 4 Days 17.90514.8Tr 20x8 P417.64mild steel1.04011.9200

147.63 €

1 4 Days 17.90514.8Tr 20x8 P417.64stainless steel1.43011.9300

72.20 €

1 4 Days 21.39417.5Tr 24x10 P521.094mild steel1.04012.8000

184.44 €

1 4 Days 21.39417.5Tr 24x10 P521.094stainless steel1.43012.7900

102.16 €

1 4 Days 26.88221.9Tr 30x12 P626.547mild steel1.04014.3300

281.38 €

1 4 Days 26.88221.9Tr 30x12 P626.547stainless steel1.43014.3800

155.39 €

1 4 Days 36.37530.5Tr 40x14 P736.02mild steel1.04018.0000

493.58 €

1 4 Days 36.37530.5Tr 40x14 P736.02stainless steel1.43018.0300

Loading...

  1. 1

Basic information

L=Length 1000 Version 2 double-start Version 1 rh-thread rolled
Item Trapezoidal Thread Spindle RoHS(kg) yes

Configure

Clear all

13Suggestion of an applicable part number.

View Part Numbers

Some specification is not specified yet.
The part number is completed.

Basic Attributes

  • D1 max.

    • 5.437
    • 10.415
    • 13.905
    • 17.905
    • 21.394
    • 26.882
    • 36.375

    Clear

  • D2

    • 4.461
    • 7.84
    • 10.8
    • 14.8
    • 17.5
    • 21.9
    • 30.5

    Clear

  • DxP=thread

    • Tr 6x2 P1
    • Tr 12x6 P3
    • Tr 16x8 P4
    • Tr 20x8 P4
    • Tr 24x10 P5
    • Tr 30x12 P6
    • Tr 40x14 P7

    Clear

  • D1 min.

    • 5.287
    • 10.191
    • 13.64
    • 17.64
    • 21.094
    • 26.547
    • 36.02

    Clear

  • Main material

    • mild steel
    • stainless steel

    Clear

  • Steel code

    • 1.0401
    • 1.4301

    Clear
