5-axis clamping system for grid plate, mild steel (41000)
· Optimum accessibility to the workpiece
· Positive clamping without pre-embossing
· Height 175 mm (extendable up to 250 mm)
· Clamping width from 22 to 236 mm (extendable)
· High clamping force on the workpiece
· Positive clamping without pre-embossing
· Height 175 mm (extendable up to 250 mm)
· Clamping width from 22 to 236 mm (extendable)
· High clamping force on the workpiece
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
Part Number
|
|---|
| 41000-4012175 |
| 41000-5012175 |
| 41000-5016175 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | B2 | B1 | D | K=grid spacing | A | A1 | Weight (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
3,029.10 € | 1 | 4 Days | 124 | 148 | 12 | 40x40 (M12) | 40 | 160 | 25.0950 | ||
3,067.74 € | 1 | 4 Days | 114 | 138 | 12 | 50x50 (M12) | 50 | 150 | 25.7500 | ||
3,067.74 € | 1 | 4 Days | 110 | 134 | 16 | 50x50 (M16) | 50 | 150 | 25.2650 |
Loading...
Basic information
| Main material | mild steel | Component material | steel | B | 190 |
|---|---|---|---|---|---|
| Item | 5-Axis Clamping System | Version 1 | for grid plate | Clamping force max.(kN) | 42 |
| H=Clamping height | 175 * | RoHS | yes |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
