Compression springs ISO 10243, heavy load (26002)

Catalog

Part number:

Still undefined. 57 possible part numbers found.

Part number list
More Information
Catalog

Part number list

Number of items

Part number

L0=Length

(mm)

Coil O.D. OD

(mm)

Di=Spiral diameter

(mm)

(N)

F max.

(N)

S max.

(mm)

Weight (ERP)

(kg)

Minimum order quantity

25	10	5	22.1	166	111	138	7.5	5	6.3	0.0042	1 pieces
32	10	5	17.5	168	112	140	9.6	6.4	8	0.0053	1 pieces
38	10	5	17.1	195	130	162	11	7.6	9.5	0.0060	1 pieces
44	10	5	15	198	132	165	13	8.8	11	0.0067	1 pieces
51	10	5	12.8	196	131	163	15	10	13	0.0078	1 pieces
64	10	5	10.7	205	137	171	19	13	16	0.0101	1 pieces
76	10	5	7.5	171	114	143	23	15	19	0.0123	1 pieces
305	10	5	2.1	192	128	160	92	61	76	0.0430	1 pieces
25	12.5	6.3	42.1	316	211	263	7.5	5	6.3	0.0061	1 pieces
32	12.5	6.3	33.2	319	212	266	9.6	6.4	8	0.0076	1 pieces
38	12.5	6.3	29.3	334	223	278	11	7.6	9.5	0.0092	1 pieces
44	12.5	6.3	24.6	325	216	271	13	8.8	11	0.0104	1 pieces
51	12.5	6.3	19.6	300	200	250	15	10	13	0.0123	1 pieces
64	12.5	6.3	15	288	192	240	19	13	16	0.0158	1 pieces
76	12.5	6.3	13.2	301	201	251	23	15	19	0.0181	1 pieces
89	12.5	6.3	11.4	304	203	254	27	18	22	0.0198	1 pieces
305	12.5	6.3	2.8	256	171	214	92	61	76	0.0677	1 pieces
25	16	8	75.7	568	379	473	7.5	5	6.3	0.0105	1 pieces
32	16	8	52.8	507	338	422	9.6	6.4	8	0.0136	1 pieces
38	16	8	48.5	553	369	461	11	7.6	9.5	0.0152	1 pieces
44	16	8	42.8	565	377	471	13	8.8	11	0.0169	1 pieces
51	16	8	37.1	568	378	473	15	10	13	0.0191	1 pieces
64	16	8	30.3	582	388	485	19	13	16	0.0247	1 pieces
76	16	8	25.7	586	391	488	23	15	19	0.0285	1 pieces
89	16	8	21.7	579	386	483	27	18	22	0.0342	1 pieces
102	16	8	19.3	591	394	492	31	20	26	0.0388	1 pieces
305	16	8	7.1	650	433	541	92	61	76	0.1402	1 pieces
25	20	10	216	1620	1080	1350	7.5	5	6.3	0.0199	1 pieces
32	20	10	168	1610	1080	1340	9.6	6.4	8	0.0247	1 pieces
38	20	10	129	1470	980	1230	11	7.6	9.5	0.0299	1 pieces
44	20	10	112	1480	986	1230	13	8.8	11	0.0343	1 pieces
51	20	10	94	1440	959	1200	15	10	13	0.0397	1 pieces
64	20	10	72.1	1380	923	1150	19	13	16	0.0498	1 pieces
76	20	10	59.7	1360	907	1130	23	15	19	0.0602	1 pieces
89	20	10	50.5	1350	899	1120	27	18	22	0.0696	1 pieces
102	20	10	44.2	1350	902	1130	31	20	26	0.0798	1 pieces
115	20	10	38.4	1320	883	1100	35	23	29	0.0893	1 pieces
127	20	10	34.1	1300	866	1080	38	25	32	0.0989	1 pieces
140	20	10	31	1300	868	1090	42	28	35	0.1084	1 pieces
152	20	10	28.2	1290	857	1070	46	30	38	0.1213	1 pieces
305	20	10	15	1370	915	1140	92	61	76	0.2372	1 pieces
25	25	12.5	380	2850	1900	2380	7.5	5	6.3	0.0356	1 pieces
32	25	12.5	276	2650	1770	2210	9.6	6.4	8	0.0462	1 pieces
38	25	12.5	220	2500	1670	2090	11	7.6	9.5	0.0557	1 pieces
44	25	12.5	185	2440	1620	2030	13	8.8	11	0.0647	1 pieces
51	25	12.5	157	2410	1600	2010	15	10	13	0.0738	1 pieces
64	25	12.5	122	2330	1560	1950	19	13	16	0.0929	1 pieces
76	25	12.5	100	2280	1520	1900	23	15	19	0.1107	1 pieces
89	25	12.5	84.4	2250	1500	1880	27	18	22	0.1292	1 pieces
102	25	12.5	73.5	2250	1500	1870	31	20	26	0.1463	1 pieces
115	25	12.5	65.2	2250	1500	1870	35	23	29	0.1641	1 pieces
127	25	12.5	57.5	2190	1460	1830	38	25	32	0.1830	1 pieces
140	25	12.5	52.1	2190	1460	1820	42	28	35	0.1998	1 pieces
152	25	12.5	48	2190	1460	1820	46	30	38	0.2167	1 pieces
178	25	12.5	40.9	2180	1460	1820	53	36	45	0.2538	1 pieces
203	25	12.5	35.7	2170	1450	1810	61	41	51	0.2909	1 pieces
305	25	12.5	22.9	2100	1400	1750	92	61	76	0.4270	1 pieces

Unit price (excluding VAT)(Unit price including VAT)	Standard shipping days

4.08 € ( 4.86 € )	4 working days
4.08 € ( 4.86 € )	4 working days
4.08 € ( 4.86 € )	4 working days
4.71 € ( 5.60 € )	4 working days
5.01 € ( 5.96 € )	4 working days
5.60 € ( 6.66 € )	4 working days
6.27 € ( 7.46 € )	4 working days
24.76 € ( 29.46 € )	4 working days
4.36 € ( 5.19 € )	4 working days
4.71 € ( 5.60 € )	4 working days
4.71 € ( 5.60 € )	4 working days
5.01 € ( 5.96 € )	4 working days
5.60 € ( 6.66 € )	4 working days
6.27 € ( 7.46 € )	4 working days
6.86 € ( 8.16 € )	4 working days
7.52 € ( 8.95 € )	4 working days
26.59 € ( 31.64 € )	4 working days
4.71 € ( 5.60 € )	4 working days
5.01 € ( 5.96 € )	4 working days
5.60 € ( 6.66 € )	4 working days
6.27 € ( 7.46 € )	4 working days
6.27 € ( 7.46 € )	4 working days
6.58 € ( 7.83 € )	4 working days
7.85 € ( 9.34 € )	4 working days
7.85 € ( 9.34 € )	4 working days
9.09 € ( 10.82 € )	4 working days
28.83 € ( 34.31 € )	4 working days
5.60 € ( 6.66 € )	4 working days
5.96 € ( 7.09 € )	4 working days
6.27 € ( 7.46 € )	4 working days
6.58 € ( 7.83 € )	4 working days
7.23 € ( 8.60 € )	4 working days
7.85 € ( 9.34 € )	4 working days
9.69 € ( 11.53 € )	4 working days
10.34 € ( 12.30 € )	4 working days
11.29 € ( 13.44 € )	4 working days
12.86 € ( 15.30 € )	4 working days
13.46 € ( 16.02 € )	4 working days
15.36 € ( 18.28 € )	4 working days
16.91 € ( 20.12 € )	4 working days
31.60 € ( 37.60 € )	4 working days
6.58 € ( 7.83 € )	4 working days
7.85 € ( 9.34 € )	4 working days
9.09 € ( 10.82 € )	4 working days
9.09 € ( 10.82 € )	4 working days
9.69 € ( 11.53 € )	4 working days
10.05 € ( 11.96 € )	4 working days
10.34 € ( 12.30 € )	4 working days
12.56 € ( 14.95 € )	4 working days
14.12 € ( 16.80 € )	4 working days
15.36 € ( 18.28 € )	4 working days
18.16 € ( 21.61 € )	4 working days
19.14 € ( 22.78 € )	4 working days
20.37 € ( 24.24 € )	4 working days
24.09 € ( 28.67 € )	4 working days
27.83 € ( 33.12 € )	4 working days
40.39 € ( 48.06 € )	4 working days

More Information

Basic information

Basic information

· Permit high alternating and permanent loads

· Can be used at operating temperatures of up to 230°

· Additionally heat-treated

· Long life expectancy

Catalog

Products homepage

Catalog (2-page spread)
