Star grip similar to DIN 6336, form K, inch (06220)
· Can be used as a clamping, retaining and fastening element
· For manually adjusting assemblies, machines and aggregates
· Form K: internal thread with cap
· Cap in various colour combinations
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
- Product data
- CAD data not available
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | D8 | H3 | Colour Cap | D=Thread | D1=Outside diameter | H=Height | Surface finish component | T=thread depth | Weight (ERP) (kg) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1.01 € | 1 | 4 Days | 12 | 8 | jet black | 10-32 | 25 | 16 | blue-passivated | 10 | 0.0060 | ||
1.08 € | 1 | 4 Days | 14 | 10 | jet black | 1/4-20 | 32 | 20 | - | 10 | 0.0085 | ||
1.23 € | 1 | 4 Days | 18 | 13 | jet black | 5/16-18 | 40 | 25 | blue-passivated | 14 | 0.0187 | ||
1.92 € | 1 | 4 Days | 22 | 17 | jet black | 3/8-16 | 50 | 32 | blue-passivated | 14 | 0.0065 | ||
3.37 € | 1 | 4 Days | 26 | 21 | jet black | 1/2-13 | 63 | 40 | blue-passivated | 18 | 0.0508 | ||
4.89 € | 1 | 4 Days | 26 | 21 | jet black | 5/8-11 | 63 | 40 | blue-passivated | 18 | 0.0425 | ||
1.08 € | 1 | 4 Days | 14 | 10 | jet black | 10-32 | 32 | 20 | - | 10 | 0.0093 | ||
1.01 € | 1 | 4 Days | 12 | 8 | light grey RAL 7035 | 10-32 | 25 | 16 | blue-passivated | 10 | 0.0065 | ||
1.01 € | 1 | 4 Days | 12 | 8 | traffic red RAL 3020 | 10-32 | 25 | 16 | blue-passivated | 10 | 0.0067 | ||
1.01 € | 1 | 4 Days | 12 | 8 | colza yellow RAL 1021 | 10-32 | 25 | 16 | blue-passivated | 10 | 0.0066 | ||
1.01 € | 1 | 4 Days | 12 | 8 | jet black | 1/4-20 | 25 | 16 | blue-passivated | 10 | 0.0079 | ||
1.08 € | 1 | 4 Days | 14 | 10 | light grey RAL 7035 | 1/4-20 | 32 | 20 | - | 10 | 0.0084 | ||
1.08 € | 1 | 4 Days | 14 | 10 | traffic red RAL 3020 | 1/4-20 | 32 | 20 | - | 10 | 0.0080 | ||
1.08 € | 1 | 4 Days | 14 | 10 | colza yellow RAL 1021 | 1/4-20 | 32 | 20 | - | 10 | 0.0085 | ||
1.92 € | 1 | 4 Days | 22 | 17 | jet black | 5/16-18 | 50 | 32 | blue-passivated | 14 | 0.0254 | ||
1.23 € | 1 | 4 Days | 18 | 13 | light grey RAL 7035 | 5/16-18 | 40 | 25 | blue-passivated | 14 | 0.0179 | ||
1.23 € | 1 | 4 Days | 18 | 13 | traffic red RAL 3020 | 5/16-18 | 40 | 25 | blue-passivated | 14 | 0.0188 | ||
1.23 € | 1 | 4 Days | 18 | 13 | colza yellow RAL 1021 | 5/16-18 | 40 | 25 | blue-passivated | 14 | 0.0179 | ||
1.23 € | 1 | 4 Days | 18 | 13 | jet black | 3/8-16 | 40 | 25 | blue-passivated | 14 | 0.0210 | ||
3.37 € | 1 | 4 Days | 26 | 21 | jet black | 3/8-16 | 63 | 40 | blue-passivated | 14 | 0.0381 | ||
1.92 € | 1 | 4 Days | 22 | 17 | light grey RAL 7035 | 3/8-16 | 50 | 32 | blue-passivated | 14 | 0.0222 | ||
1.92 € | 1 | 4 Days | 22 | 17 | traffic red RAL 3020 | 3/8-16 | 50 | 32 | blue-passivated | 14 | 0.0229 | ||
1.92 € | 1 | 4 Days | 22 | 17 | colza yellow RAL 1021 | 3/8-16 | 50 | 32 | blue-passivated | 14 | 0.0221 | ||
1.92 € | 1 | 4 Days | 22 | 17 | jet black | 1/2-13 | 50 | 32 | blue-passivated | 18 | 0.0362 | ||
3.37 € | 1 | 4 Days | 26 | 21 | light grey RAL 7035 | 1/2-13 | 63 | 40 | blue-passivated | 18 | 0.0533 | ||
3.37 € | 1 | 4 Days | 26 | 21 | traffic red RAL 3020 | 1/2-13 | 63 | 40 | blue-passivated | 18 | 0.0021 | ||
3.37 € | 1 | 4 Days | 26 | 21 | colza yellow RAL 1021 | 1/2-13 | 63 | 40 | blue-passivated | 18 | 0.0531 | ||
4.89 € | 1 | 4 Days | 26 | 21 | light grey RAL 7035 | 5/8-11 | 63 | 40 | blue-passivated | 18 | 0.0418 | ||
4.89 € | 1 | 4 Days | 26 | 21 | traffic red RAL 3020 | 5/8-11 | 63 | 40 | blue-passivated | 18 | 0.0424 | ||
4.89 € | 1 | 4 Days | 26 | 21 | colza yellow RAL 1021 | 5/8-11 | 63 | 40 | blue-passivated | 18 | 0.0403 | ||
1.08 € | 1 | 4 Days | 14 | 10 | light grey RAL 7035 | 10-32 | 32 | 20 | - | 10 | 0.0150 | ||
1.08 € | 1 | 4 Days | 14 | 10 | traffic red RAL 3020 | 10-32 | 32 | 20 | - | 10 | 0.0092 | ||
1.08 € | 1 | 4 Days | 14 | 10 | colza yellow RAL 1021 | 10-32 | 32 | 20 | - | 10 | 0.0089 | ||
1.01 € | 1 | 4 Days | 12 | 8 | light grey RAL 7035 | 1/4-20 | 25 | 16 | blue-passivated | 10 | 0.0059 | ||
1.01 € | 1 | 4 Days | 12 | 8 | traffic red RAL 3020 | 1/4-20 | 25 | 16 | blue-passivated | 10 | 0.0060 | ||
1.01 € | 1 | 4 Days | 12 | 8 | colza yellow RAL 1021 | 1/4-20 | 25 | 16 | blue-passivated | 10 | 0.0061 | ||
1.92 € | 1 | 4 Days | 22 | 17 | light grey RAL 7035 | 5/16-18 | 50 | 32 | blue-passivated | 14 | 0.0249 | ||
1.92 € | 1 | 4 Days | 22 | 17 | traffic red RAL 3020 | 5/16-18 | 50 | 32 | blue-passivated | 14 | 0.0248 | ||
1.92 € | 1 | 4 Days | 22 | 17 | colza yellow RAL 1021 | 5/16-18 | 50 | 32 | blue-passivated | 14 | 0.0247 | ||
1.23 € | 1 | 4 Days | 18 | 13 | light grey RAL 7035 | 3/8-16 | 40 | 25 | blue-passivated | 14 | 0.0230 | ||
1.23 € | 1 | 4 Days | 18 | 13 | traffic red RAL 3020 | 3/8-16 | 40 | 25 | blue-passivated | 14 | 0.0110 | ||
1.23 € | 1 | 4 Days | 18 | 13 | colza yellow RAL 1021 | 3/8-16 | 40 | 25 | blue-passivated | 14 | 0.0153 | ||
3.37 € | 1 | 4 Days | 26 | 21 | light grey RAL 7035 | 3/8-16 | 63 | 40 | blue-passivated | 14 | 0.0375 | ||
3.37 € | 1 | 4 Days | 26 | 21 | traffic red RAL 3020 | 3/8-16 | 63 | 40 | blue-passivated | 14 | 0.0373 | ||
3.37 € | 1 | 4 Days | 26 | 21 | colza yellow RAL 1021 | 3/8-16 | 63 | 40 | blue-passivated | 14 | 0.0372 | ||
1.92 € | 1 | 4 Days | 22 | 17 | light grey RAL 7035 | 1/2-13 | 50 | 32 | blue-passivated | 18 | 0.0379 | ||
1.92 € | 1 | 4 Days | 22 | 17 | traffic red RAL 3020 | 1/2-13 | 50 | 32 | blue-passivated | 18 | 0.0378 | ||
1.92 € | 1 | 4 Days | 22 | 17 | colza yellow RAL 1021 | 1/2-13 | 50 | 32 | blue-passivated | 18 | 0.0378 | ||
1.01 € | 1 | 4 Days | 12 | 8 | jet black | 8-32 | 25 | 16 | blue-passivated | 10 | 0.0071 | ||
1.01 € | 1 | 4 Days | 12 | 8 | light grey RAL 7035 | 8-32 | 25 | 16 | blue-passivated | 10 | 0.0060 | ||
1.01 € | 1 | 4 Days | 12 | 8 | traffic red RAL 3020 | 8-32 | 25 | 16 | blue-passivated | 10 | 0.0070 | ||
1.01 € | 1 | 4 Days | 12 | 8 | colza yellow RAL 1021 | 8-32 | 25 | 16 | blue-passivated | 10 | 0.0070 |
Loading...
Basic information
| Component material | steel | DIN | similar to DIN 6336 | Form | K |
|---|---|---|---|---|---|
| Item | Star Grip | Main colour | black | Main material | Thermoplastic |
| Thread type | internal thread | RoHS | yes |
