Socket Conforming to Card Bus Complying with PC Card Standards, IC9 Series
- Volume Discount
Product Details:
Manufacturer part number: IC9-68RD-0.635SF(51)
Brand: HIROSE ELECTRONIC
Price: 5.65 €
Delivery time: 5 Days
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
IC9-68RD-0.635SF(51)
Basic information
| Connector series initials | G/H/I | G/H/I | IC | Contact sex | Female |
|---|---|---|---|---|---|
| Number Of Cores | 68 | Connector Type | For PCB | Rated Current(A) | 0.5 |
| Allowable Voltage(V) | AC125 | Wiring Method | Circuit Board Mounting (SMT) | Connection direction | Angle |
| Plating of part touching terminal | Gold | Product Category | Card connector | Features | Eccentricity 0.3 mm |
| Contact Pitch(mm) | 1.27 | Operating Temperature Range(°C) | -20 to +60 | Terminal pitch(mm) | 0.635 |
This page is Socket Conforming to Card Bus Complying with PC Card Standards, IC9 Series, part number IC9-68RD-0.635SF(51).
You can find the detail information about specifications and dimensions on part number IC9-68RD-0.635SF(51).
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
