Circuit Board-to-Cable Connector (in Equipment), KX14/KX15 Series
- Volume Discount
[Features]
· Compatible with parallel board intervals of 4–9-mm (1-mm each).
· Two, straight-type, insulator heights are available for KX14 (receptacle), and three for KX15 (plug).
· When installing parallel boards, the board interval dimensions can be selected between 4–9-mm (1-mm each) by using different receptacle and plug combinations.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Applicable pin/contact | Number Of Cores | Connection direction | Circuit Board Mounting Height (mm) | Insulator material | Hold-down | Special Notes | |
|---|---|---|---|---|---|---|---|---|---|---|---|
4.31 € | 2 | Available | 5 Days | Female (socket) | 20 | Straight | 3.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
4.45 € | 2 | Available | 5 Days | Female (socket) | 20 | Straight | 6.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
5.54 € | 1 | Available | 5 Days | Female (socket) | 30 | Straight | 3.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
5.62 € | 1 | Available | 5 Days | Female (socket) | 30 | Straight | 6.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
5.73 € | 1 | Available | 5 Days | Female (socket) | 30 | Straight | 9.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
6.74 € | 1 | Available | 5 Days | Female (socket) | 40 | Straight | 9.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
10.33 € | 1 | Available | 5 Days | Female (socket) | 60 | Straight | 3.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
9.04 € | 1 | Available | 5 Days | Female (socket) | 60 | Straight | 6.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
10.24 € | 1 | Available | 5 Days | Female (socket) | 70 | Straight | 9.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
11.33 € | 1 | Available | 5 Days | Female (socket) | 80 | Straight | 6.55 | Glass filled LCP | Available | With reverse insertion prevention key | |
4.03 € | 2 | Available | 5 Days | Male (plug) | 20 | Straight | 4.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
4.40 € | 2 | Available | 5 Days | Male (plug) | 20 | Straight | 5.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
4.40 € | 2 | Available | 5 Days | Male (plug) | 20 | Angle | 5.75 | Glass filled LCP | Available | With reverse insertion prevention key | |
5.54 € | 1 | Available | 5 Days | Male (plug) | 30 | Straight | 5.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
5.65 € | 1 | Available | 5 Days | Male (plug) | 30 | Angle | 5.75 | Glass filled LCP | Available | With reverse insertion prevention key | |
7.83 € | 1 | Available | 5 Days | Male (plug) | 50 | Straight | 4.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
7.83 € | 1 | Available | 5 Days | Male (plug) | 50 | Straight | 5.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
9.20 € | 1 | Available | 5 Days | Male (plug) | 60 | Straight | 4.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
9.20 € | 1 | Available | 5 Days | Male (plug) | 60 | Straight | 5.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
9.37 € | 1 | Available | 5 Days | Male (plug) | 60 | Angle | 5.75 | Glass filled LCP | Available | With reverse insertion prevention key | |
11.27 € | 1 | Available | 5 Days | Male (plug) | 80 | Straight | 4.75 | Glass filled PPS | Available | With reverse insertion prevention key | |
11.90 € | 1 | Available | 5 Days | Male (plug) | 80 | Angle | 5.75 | Glass filled LCP | NA | Reverse insertion prevention key, with hex nut |
