JST (JST MANUFACTURING)

HL Connector (for Relay Connections)【1 to 6000 pieces】

HL Connector (for Relay Connections)

Part number:

Still undefined. 6 possible part numbers found.
Quantity:

Part number list

Number of items
  • 1
    • Part number
    BSF-21T-P1.4
    BSM-21T-P1.4
    HLP-02V
    HLP-03V
    HLR-03V
    HLR-08V

    Connector Shape

    Applicable pin/contact

    Number Of Cores

    Allowable Current

    (A)

    Product Category

    Specifications

    Features

    Color

    Pitch

    (mm)

    		Minimum order quantity
    Round
    Female (socket)
    -
    AC/DC7
    Contact
    Individual
    -
    -
    -
    1 packs

    6000 pieces

    Round
    Male (plug)
    -
    AC/DC7
    Contact
    Individual
    -
    -
    -
    1 packs

    5000 pieces

    Square shape
    Female (socket)
    2
    AC/DC7
    Plug Housing
    For socket contact
    -
    White
    3.96
    3 packs

    10 pieces

    Square shape
    Female (socket)
    3
    AC/DC6
    Plug Housing
    For socket contact
    -
    White
    3.96
    9 pieces
    Square shape
    Male (plug)
    3
    AC/DC6
    Receptacle housing
    For pin contact
    With panel lock
    White
    3.96
    2 packs

    10 pieces

    Square shape
    Male (plug)
    8
    AC/DC4
    Receptacle housing
    For pin contact
    With panel lock
    White
    3.96
    5 pieces
    Unit price (excluding VAT)(Unit price including VAT)
    Standard shipping days
    275.72 €
    ( 328.11 € )
    6 working days
    195.98 €
    ( 233.22 € )
    6 working days
    1.53 €
    ( 1.82 € )
    6 working days
    0.49 €
    ( 0.58 € )
    6 working days
    2.18 €
    ( 2.59 € )
    6 working days
    1.93 €
    ( 2.30 € )
    10 working days
  • 1

    • More Information

    Basic information

    Utilizing free spring contact structure, this connector is designed with a retainer, inner lock, and other safety features.

    [Features]
    · A connector with 3.96-mm pitch that utilizes free spring contact structure.
    · Besides the excellent reliability offered by the unique stress-relaxation ability, a retainer, inner lock, and other safety features are also designed into the product.
    · Utilizing a free spring contact structure.
    · Housing lance method.
    ▪ Interlock structure.
    · A retainer.
    · Panel lock structure.
