CQ Motoring Wiring Insert
- Volume Discount
CQ motoring wiring insert
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| CQF 04/2 |
| CQF 08 |
| CQM 04/2 |
| CQM 08 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | RoHS | Applicable pin/contact | Number Of Cores | Allowable Current (A) | Allowable Voltage (V) | Part names | Application | |
|---|---|---|---|---|---|---|---|---|---|---|---|
8.19 € | 1 | Available | 5 Days | 10 | Female (socket) | 6 | 40 | 690 | Female insert | For female contacts | |
7.13 € | 1 | Available | 5 Days | 10 | Female (socket) | 8 | 16 | 500 | Female insert | For female contacts | |
9.99 € | 1 | Available | 5 Days | 10 | Male (plug) | 6 | 40 | 690 | Male insert | For male contacts | |
8.20 € | 1 | Available | 5 Days | 10 | Male (plug) | 8 | 16 | 500 | Male insert | For male contacts |
Loading...
Basic information
| Connector Shape | Square shape | Connector series initials | A/B/C | Application | Cable Connection |
|---|---|---|---|---|---|
| Wire connection method | Crimp | Connection direction | Straight | Representative Standard | UL / CUL / CSA |
| Operating Temperature Range (Min)(°C) | -40 | Operating Temperature Range (Max)(°C) | +125 | Enclosure size(mm) | 32.13 |
| Material | Flame resistant thermoplastic resin | Note | Contacts sold separately | Other standards | GOST |
Configure
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
