Sherlock™ 2.00mm Pitch PCB Housing (35507)
- Volume Discount
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 35507-0200 |
| 35507-0300 |
| 35507-0400 |
| 35507-0600 |
| 35507-0700 |
| 35507-0800 |
| 35507-0900 |
| 35507-1000 |
| 35507-1200 |
| 35507-1300 |
| 35507-1500 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Number Of Cores | |
|---|---|---|---|---|---|
0.06 € | 1 | 5 Days | 2 | ||
0.09 € | 1 | 5 Days | 3 | ||
0.09 € | 1 | 5 Days | 4 | ||
0.11 € | 1 | 5 Days | 6 | ||
0.12 € | 1 | 5 Days | 7 | ||
0.12 € | 1 | 5 Days | 8 | ||
0.14 € | 1 | 5 Days | 9 | ||
0.14 € | 1 | 5 Days | 10 | ||
0.14 € | 1 | 5 Days | 12 | ||
0.12 € | 1 | 5 Days | 13 | ||
0.16 € | 1 | 5 Days | 15 |
Loading...
Basic information
| Connector Shape | Square shape | Connector series initials | Number | Applicable pin/contact | Female (socket) |
|---|---|---|---|---|---|
| Application | Cable Connection | Allowable Current(A) | 2 | Connection direction | Straight |
| Protection function (environmentally resistant) | N/A | Representative Standard | UL / CSA | Pitch(mm) | 2.00 |
| Number of Columns | 1 | Mating lock | Available | Panel Mount | NA |
| Color | Natural Color | Conforming terminal | 50212 | Mating Partner | 35362, 35363 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
