Standard .062 Inch Housing (1625-NP)
- Volume Discount
A Molex 3.68 mm pitch connector for standard wire-to-wire connections. Single-row, double-row, and panel mount types are available. (Mating housing: 1625-NP, Compatible terminal: 1560/1854)
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| 1625-01P |
| 1625-02P1 |
| 1625-04P |
| 1625-04P1 |
| 1625-06P |
| 1625-06P1 |
| 1625-2P2 |
| 1625-3P |
| 1625-3P1 |
| 1625-9P1 |
| 1625-12P |
| 1625-12P1 |
| 1625-15P |
| 1625-15P1 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Number Of Cores | Representative Standard | Number of Columns | Panel Mount | Conforming terminal | Mating Partner | |
|---|---|---|---|---|---|---|---|---|---|---|
0.59 € | 8 | Available | 5 Days | 1 | UL / TUV / CSA | - | Available | - | - | |
1.35 € | 4 | Available | 5 Days | 2 | UL / TUV / CSA | - | NA | - | - | |
0.94 € | 7 | Available | 5 Days | 4 | UL / TUV / CSA | - | Available | - | - | |
0.94 € | 7 | Available | 5 Days | 4 | UL / TUV / CSA | - | NA | - | - | |
0.97 € | 5 | Available | 5 Days | 6 | UL / TUV / CSA | 3 | Available | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 39-03-2069 | |
1.53 € | 6 | Available | 5 Days | 6 | UL / TUV / CSA | 3 | NA | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 39-03-2068, 39-03-2069 | |
0.94 € | 5 | Available | 5 Days | 2 | UL / TUV / CSA | 1 | Available | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1022, 03-06-1023, 03-06-6023 | |
0.61 € | 8 | Available | 5 Days | 3 | UL / TUV / CSA | 1 | Available | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1032, 03-06-1033 | |
0.60 € | 8 | Available | 5 Days | 3 | UL / TUV / CSA | 1 | NA | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1031, 03-06-1032, 03-06-1033, 03-06-1034, 03-06-1038, 03-06-6031 | |
0.98 € | 5 | Available | 5 Days | 9 | UL / TUV / CSA | 3 | NA | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1092 | |
1.14 € | 4 | Available | 5 Days | 12 | UL / TUV / CSA | 3 | Available | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1122 | |
1.21 € | 4 | Available | 5 Days | 12 | UL / TUV / CSA | 3 | NA | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1121, 03-06-1122 | |
1.25 € | 4 | Available | 5 Days | 15 | UL / TUV / CSA | 3 | Available | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1152, 03-06-6152 | |
1.29 € | 4 | Available | 5 Days | 15 | UL / CSA | 3 | NA | 1561, 4559, 4529, 2190, 2189, 1787, 1855, 1560, 1786, 1854, 1778, 1779 | 03-06-1152, 03-06-6152, 03-06-6155 |
Loading...
Basic information
| Connector Shape | Square shape | Connector series initials | Number | Applicable pin/contact | Male (plug) |
|---|---|---|---|---|---|
| Application | Cable Connection | Allowable Current(A) | 5 | Connection direction | Straight |
| Protection function (environmentally resistant) | N/A | Pitch(mm) | 3.68 | Mating lock | Available |
| Material | NYLON 66 | Color | Natural Color | Note | UL94V-2 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
