Block Power Supply S8TS
Omron product. Power supplies can be connected. Capacity increase is possible with dry cell batteries
[Features]
· 1 model can take 30-120W (12V type).
· 1 model can take 60-240W (24V type).
· Multi power supplies with different output voltages (5 V / 12V / 24V) are easy to configure.
· Uses N+1 redundant operation to help improve the reliability of power supply systems (12V/24V.)
· Lead-free soldering.
· Input condition: DC input DC80 to 370V (EC directives and various safety standards are not applicable).
[Features]
· 1 model can take 30-120W (12V type).
· 1 model can take 60-240W (24V type).
· Multi power supplies with different output voltages (5 V / 12V / 24V) are easy to configure.
· Uses N+1 redundant operation to help improve the reliability of power supply systems (12V/24V.)
· Lead-free soldering.
· Input condition: DC input DC80 to 370V (EC directives and various safety standards are not applicable).
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| S8TS-02505 |
| S8TS-03012 |
| S8TS-06024 |
| S8TS-06024-E1 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Capacity (W) | Output voltage (Single only) | Rated output current (single only) (A) | Included Function | Note | |
|---|---|---|---|---|---|---|---|---|---|
299.00 € | 1 | 7 Days | 25 | 5 V DC | 5 | Alarm Output | - | ||
284.20 € | 1 | 7 Days | 30 | 12 V DC | 2.5 | Parallel / Alarm Output | - | ||
213.30 € | 1 | 7 Days | 60 | 24 V DC | 2.5 | Parallel / Alarm Output | - | ||
229.40 € | 1 | 7 Days | 60 | 24 V DC | 2.5 | Parallel / Alarm Output | Bus line connector included |
Loading...
Basic information
| Shape | DIN rail direct attachment | Single/multi | Single | Input Voltage | AC/DC |
|---|---|---|---|---|---|
| Input/output terminal shape | Screw | Safety standards | CE / UL / CUL | Dimension height(mm) | 128.1 |
| Dimension width(mm) | 48 | Dimension depth(mm) | 120 |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
