Power Relay G7X
[Features]
· High-grade power relay with cut-off capability DC110V, 30A, L/R = 40 ms.
· Main contact (2a) for cutting off DC110V 30A (short time rating).
· Auxiliary contact (1a, 1b) built-in optimal for answer back.
· Each terminal is mounted to the printed circuit board.
· Main contact terminal has shared screw wiring / circuit board wiring.
· Compact and flat due to high density design.
· Insulation materials meet UL94V-0 flame resistance standards.
· High-grade power relay with cut-off capability DC110V, 30A, L/R = 40 ms.
· Main contact (2a) for cutting off DC110V 30A (short time rating).
· Auxiliary contact (1a, 1b) built-in optimal for answer back.
· Each terminal is mounted to the printed circuit board.
· Main contact terminal has shared screw wiring / circuit board wiring.
· Compact and flat due to high density design.
· Insulation materials meet UL94V-0 flame resistance standards.
Part Number
Once your search is narrowed to one product,
the corresponding part number is displayed here.
Part Number
|
|---|
| G7X-4BP-JD DC24 |
| G7X-4BP-JD DC100/110 |
| Part Number |
Standard Unit Price
| Minimum order quantity | Volume Discount | Coil rated voltage (DC) (V) | |
|---|---|---|---|---|---|
113.96 € | 1 | 6 Days | 24 | ||
113.96 € | 1 | 6 Days | 100/110 |
Loading...
Basic information
| Application | Power | Contact Configuration | 2a | Terminal shape | Screw terminal / printed circuit board terminal |
|---|---|---|---|---|---|
| Contact rated current (minimum value for AC and DC)(A) | 5 | Dimension height(mm) | 51 | Dimension width(mm) | 51 |
| Dimension depth(mm) | 30 | Type | Electrically compliant auxiliary power relays | Auxiliary contact configuration | 1a1b |
| Contact mechanism | Single | AC rated load (AUX contact) | AC220V/1A | DC rated load | DC110V/5A |
| DC rated load (AUX contact) | DC110V/0.3A |
- The specifications and dimensions of some parts may not be fully covered. For exact details, refer to manufacturer catalogs .
