AGM type metal cable grand high waterproof type

AGM type metal cable grand high waterproof type
  • Promotional pricing
  • Volume Discount

TAKACHI ELECTRONICS ENCLOSURE

TAKACHI ELECTRONICS ENCLOSURE

[Features]
A highly waterproof metal cable gland of protection level IP6810 bar/30 minutes.
Screw sizes are M6-M50PG7 to PG16. The corresponding cable external diameters range from φ2mm to φ42mm.

Data sheet

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.


Data to be displayed
30
45
60
  1. 1
Part Number
AGM6-2.5
AGM6-3
AGM6-3.5
AGM7PG-5
AGM8-5
AGM10-6
AGM11PG-8.5
AGM12-8
AGM13PG-11
AGM16-10.5
AGM20-15
AGM25-20
AGM32-25.5
AGM40-28.5
AGM40-33
AGM50-37
AGM50-42
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSShape Outer Diameter Of Cable Used Screw Standard Material Color Protection Function (Environmental Resistance) Representative Standard Screw Size Conforming wire diameter φ
(mm)

7.33 €

2.49 €

1 Available Same day

Stock

10Integrated TypeΦ2～2.5mmMetric ThreadMetalOtherWaterproofCE / UL / CULM6 x 1.02-2.5 (cable diameter)

5.22 €

1.83 €

1 Available Same day

Stock

10Integrated TypeΦ2.5～3.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM6 x 1.02.5-3.0 (cable diameter)

5.23 €

1 Available Same day

Stock

10Integrated TypeΦ3.0～3.5mmMetric ThreadMetalOtherWaterproofCE / UL / CULM6 x 1.03.0-3.5 (cable diameter)

6.41 €

1 Available Same day

Stock

10Integrated TypeΦ3.5～5.0mmPg ThreadMetalOtherWaterproofCE / UL / CULPG73.5-4.7 (cable diameter)

5.88 €

1 Available 5 Days 10Integrated TypeΦ3.5～4.7mmMetric ThreadMetalOtherWaterproofCE / UL / CULM8 x 1.254.0-6.0 (cable diameter)

6.19 €

1 Available 5 Days 10Integrated TypeΦ4.0～6.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM10 x 1.54.0-6.0 (cable diameter)

12.46 €

3.74 €

1 Available Same day

Stock

10Integrated TypeΦ5.5～8.5mmPg ThreadMetalOtherWaterproofCE / UL / CULPG115.5-8.5 (cable diameter)

5.94 €

1 Available Same day

Stock

10Integrated TypeΦ6.5～8.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM12 x 1.56.5-8.0 (cable diameter)

14.85 €

4.46 €

1 Available Same day

Stock

10-------PG138.0-11.0 (cable diameter)

8.87 €

1 Available 5 Days 10Integrated TypeΦ8.0～10.5mmMetric ThreadMetalOtherWaterproofCE / UL / CULM16 x 1.58.0-10.5 (cable diameter)

10.27 €

3.49 €

1 Available Same day

Stock

10Integrated TypeΦ11.0～15.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM20 x 1.511.0-15.0 (cable diameter)

22.55 €

6.77 €

1 Available Same day

Stock

10Integrated TypeΦ16.0～20.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM25 x 1.516.0-20.0 (cable diameter)

26.96 €

9.44 €

1 Available Same day

Stock

10-------M32 x 1.521.0-25.5 (cable diameter)

45.32 €

15.86 €

1 Available Same day

Stock

10Integrated TypeΦ24.0～28.5mmMetric ThreadMetalOtherWaterproofCE / UL / CULM40 x 1.524.0-28.5 (cable diameter)

45.32 €

15.86 €

1 Available Same day

Stock

10Integrated TypeΦ28.5～33.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM40 x 1.528.5-33.0 (cable diameter)

88.72 €

1 Available 5 Days 10Integrated TypeΦ33.0～37.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM50 x 1.533.0-37.0 (cable diameter)

73.58 €

32.38 €

1 Available Same day

Stock

10Integrated TypeΦ37.0～42.0mmMetric ThreadMetalOtherWaterproofCE / UL / CULM50 x 1.537.0-42.0 (cable diameter)

Loading...

  1. 1

Basic information

Color specifications/surface treatment Nickel plated (cap - connector body - nut)/black (rubber bushing - o-ring) Material Brass (cap, connector main body, nut)/TPE (rubber bushing)/NBR (O-ring) Standard(IP) IP68
Representative Standard CE, UL, CUL
