Spring Type Connector, 734 Series, 3.5 mm Pitch, Female with Lock Mechanism

Spring Type Connector, 734 Series, 3.5 mm Pitch, Female with Lock Mechanism
  • Volume Discount
A Wago 734 Series female spring-type connector with locking mechanism to enable male-side connection to the 734–300 Series connectors. Compatible boards: 734–100/400 Series. An extremely compact connector.

Part Number

Once your search is narrowed to one product,
the corresponding part number is displayed here.

Part Number
734-102/037-000
734-103/037-000
734-104/037-000
734-105/037-000
734-106/037-000
734-107/037-000
734-108/037-000
734-110/037-000
734-112/037-000
734-114/037-000
734-116/037-000
734-120/037-000
734-124/037-000
Part Number
Standard Unit Price
Minimum order quantityVolume Discount
Standard
Shipping Days
?
RoHSNumber Of Cores

2.42 €

1 Same day

Stock

102

5.69 €

2 Available Same day

Stock

103

4.20 €

1 Available Same day

Stock

104

8.41 €

1 Available Same day

Stock

105

6.28 €

2 Available Same day

Stock

106

7.08 €

1 Available 5 Days 107

7.27 €

1 Available Same day

Stock

108

8.89 €

1 Available Same day

Stock

1010

9.95 €

1 Available Same day

Stock

1012

13.12 €

1 Available 5 Days 1014

14.83 €

1 Available 5 Days 1016

18.27 €

1 Available 5 Days 1020

21.74 €

1 Available 5 Days 1024

Loading...

  1. 1

Basic information

Connector Shape Square shape Connector series initials M/N/O M/N/O MCS-MINI
Applicable pin/contact Female (socket) Application Cable Connection Allowable Current(A) 10
Allowable Voltage(V) 300 Wire connection method Screwless Connection direction Straight
Representative Standard UL / CUL / CSA Product Type With locking device Color Light Gray
Pin pitch(mm) 3.5 Conforming Wire Single wire / flexible stranded wire / flexible stranded wire (with insulation color ferrule) / flexible stranded wire (no insulation color ferrule) Single wire conforming cross-section(mm2) 0.08 to 0.5
Flexible stranded wire Conforming cross-sectional area(mm2) 0.08 to 0.5 Flexible stranded wire (insulated collar attached ferrule) conforming cross-sectional area(mm2) 0.25–1.0 Flexible stranded wire (ferrule without insulated collar ) conforming cross-sectional area(mm2) 0.25 to 1.5
Wire conforming size(AWG) 28 to 14 Maximum Outer Diameter of Coat(mm) 3.4 Insulation materials Nylon 6.6
Flame-Retardant Grade UL94/V0 Contact materials Copper Alloy Contact surface treatment Tin Plating
Supported accessories Marking accessories/operating tools/direct printing/mounting adapter/strain relief housing/strain relief plate
